DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PQP3-D24-S3-MDC DC CONVERTER 3.3V 2.5W |
331 |
|
Datasheet | PQP3-M | 8-SMD Module, 5 Leads | Tube | Not For New Designs | Isolated Module | 1 | 18V | 36V | 3.3V | - | - | - | 758mA | 2.5 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 74% | - | - | Surface Mount | - | - | CE | - |
|
|
PQP3-D24-S3-M-TRDC DC CONVERTER 3.3V 2.5W |
211 |
|
Datasheet | PQP3-M | 8-SMD Module, 5 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 18V | 36V | 3.3V | - | - | - | 758mA | 2.5 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 74% | - | - | Surface Mount | - | - | CE | - |
|
PRM1W-E12-D12-SDC-DC ISOLATED, 1 W, 4.5~36 VDC |
112 |
|
Datasheet | PRM1W-S (1W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 2 | 4.5V | 36V | 12V | -12V | - | - | 42mA, 42mA | 1 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 74% | - | - | Through Hole | - | - | CE | 62368-1 |
|
PEM2-S12-D15-SDC DC CONVERTER +/-15V 2W |
139 |
|
Datasheet | PEM2-S (2W) | 7-SIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 2 | 10.8V | 13.2V | 15V | -15V | - | - | 66.6mA, 66.6mA | 2 W | 3 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 84% | - | - | Through Hole | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 60950-1 |
|
PYBJ6-D12-S12-ODDC DC CONVERTER 12V 6W |
332 |
|
Datasheet | PYBJ6 (6W) | 6-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 18V | 12V | - | - | - | 500mA | 6 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C | 84% | - | - | Through Hole | - | - | CB Scheme, IEC, UL | 62368-1 |
|
V7803-1000RDC DC CONVERTER 3.3V 3.3W |
602 |
|
Datasheet | V78-1000 | 3-SIP Module | Tube | Obsolete | Linear Regulator Replacement | 1 | 4.75V | 28V | 3.3V | - | - | - | 1A | 3.3 W | - | ITE (Commercial) | OTP, SCP | -40°C ~ 85°C | 90% | - | - | Through Hole, Right Angle | - | - | - | - |
|
PQMC1-D12-S15-SDC DC CONVERTER 15V 1W |
3,290 |
|
Datasheet | PQMC1-S (1W) | 8-SIP Module, 7 Leads | Bulk | Not For New Designs | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 67mA | 1 W | 1.5 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 81% | - | - | Through Hole | - | Enable, Active Low | EN | 55024; 55032 Class A |
|
VIBLSD1-S5-S12-DIPDC DC CONVERTER 12V 1W |
2,130 |
|
Datasheet | VIBLSD1-DIP (1W) | 14-DIP Module (300 mil, 5 Leads) | Bulk | Obsolete | Isolated Module | 1 | 4.75V | 5.25V | 12V | - | - | - | 83mA | 1 W | 1 kV | ITE (Commercial) | SCP | -40°C ~ 85°C | 71% | - | - | Through Hole | - | - | - | - |
|
PDQ2-D48-S12-SDC DC CONVERTER 12V 2W |
2,304 |
|
Datasheet | PDQ2-S (2W) | 8-SIP Module, 7 Leads | Bulk | Active | Isolated Module | 1 | 36V | 75V | 12V | - | - | - | 167mA | 2 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, SCP | -40°C ~ 100°C | 82% | - | - | Through Hole | - | Enable, Active Low | EN | 55032 Class A |
|
PUZ3-D12-S24-DDC DC CONVERTER 24V 3W |
238 |
|
Datasheet | PUZ3-D (3W) | 24-DIP Module, 8 Leads | Tube | Not For New Designs | Isolated Module | 1 | 9V | 18V | 24V | - | - | - | 125mA | 3 W | 1.5 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
