Panel Indicators, Pilot Lights
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Lamp Color | Lens Color | Lens Transparency | Ratings | Voltage | Current | Panel Cutout Shape | Panel Cutout Dimensions | Lens Size | Lens Style | Millicandela Rating | Wavelength - Peak | Viewing Angle | Termination Style | Ingress Protection | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
6211141304F22MM FLTPMI RGY 3VDC W/TERM |
3,968 |
|
Datasheet | 621 | Bag | Active | LED | Red, Green, Yellow | - | Diffused | DC | 3V | 15mA Red, 15mA Green, 15mA Yellow | Round | 0.87" (22.00mm) | 13.80mm Dia | Round with Flat Top | 115mcd Red, 110mcd Green, 435mcd Yellow | - | - | Solder Lug | IP66/IP67, NEMA 4X | - |
|
5087538504HOLDER W/COLLAR SOLDER CUPS |
3,965 |
|
Datasheet | 508 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
6561122303F1/2" FLT R/G 5VDC W/LEAD |
1,084 |
|
Datasheet | 656 | Bag | Active | LED | Green, Red | - | Clear | DC | 5V | 8mA Green, 11mA Red | Round | 0.50" (12.70mm) | - | Round with Flat Top | 910mcd Green, 330mcd Red | - | - | Wire Leads - 5.84" (148.21mm) | IP66/IP67, NEMA 4X | - |
|
6211123304F22MM FLTPMI RGB 12VDC W/TERM |
2,431 |
|
Datasheet | 621 | Bag | Active | LED | Red, Green, Blue (RGB) | - | Diffused | DC | 12V | 15mA Red, 15mA Green, 15mA Blue | Round | 0.87" (22.00mm) | 13.80mm Dia | Round with Flat Top | 200mcd Red, 250mcd Green, 300mcd Blue | - | - | Solder Lug | IP66/IP67, NEMA 4X | - |
|
5088745504HOLDER W/COLLAR TURRET |
4,367 |
|
Datasheet | 508 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
657-2415-303FPMI, DOME, RG, 10-30VDC |
2,218 |
|
Datasheet | 657 | Bag | Active | LED | Green, Red | White | Diffused | DC | 10V ~ 30V | 20mA | Round | 0.69" (17.46mm) | 16.50mm Dia | Round with Domed Top | 500mcd Green, 255mcd Red | - | - | Wire Leads - 6" (152.40mm) | IP67, NEMA 4X | - |
|
657-1485-303FPMI, FLAT, RGB, 10-30VDC |
3,835 |
|
Datasheet | 657 | Bag | Active | LED | Red, Green, Blue (RGB) | White | Diffused | DC | 10V ~ 30V | 20mA | Round | 0.69" (17.46mm) | 16.50mm Dia | Round with Flat Top | 270mcd Red, 515mcd Green, 90mcd Blue | - | - | Wire Leads - 6" (152.40mm) | IP67, NEMA 4X | - |
|
657-1495-303FPMI, FLAT, GRY, 10-30VDC |
1,726 |
|
Datasheet | 657 | Bag | Active | LED | Green, Red, Yellow | White | Diffused | DC | 10V ~ 30V | 20mA | Round | 0.69" (17.46mm) | 16.50mm Dia | Round with Flat Top | 515mcd Green, 270mcd Red, 310mcd Yellow | - | - | Wire Leads - 6" (152.40mm) | IP67, NEMA 4X | - |
|
800103003504T-1 3/4 MIDGET FLANGE BASE |
3,877 |
|
Datasheet | 800 | Bag | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
103310105103LED BASE T-3 1/4 PANEL OIL TIGHT |
4,898 |
|
- |
103 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
