Panel Indicators, Pilot Lights
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Lamp Color | Lens Color | Lens Transparency | Ratings | Voltage | Current | Panel Cutout Shape | Panel Cutout Dimensions | Lens Size | Lens Style | Millicandela Rating | Wavelength - Peak | Viewing Angle | Termination Style | Ingress Protection | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5561604304FLED PNL MT 1" 24V WT FLAT GRN |
3,238 |
|
Datasheet | 556 | Bulk | Active | LED | Green | - | - | DC | 24V | 32mA | Round | 1.12" (28.45mm) | - | Round with Flat Top | - | - | - | Screw Terminal | IP66, NEMA 4X | - |
|
5580101027FLED PMI .158" RED PVC FREE |
4,701 |
|
Datasheet | 558 | Bulk | Active | LED | Red | Red | Diffused | Vf (Typ), If (Max) | 2V | 20mA | Round | 0.16" (4.06mm) | 3mm, T-1 | Round with Domed Top | 10mcd | 650nm | - | Wire Leads - 14" (355.60mm) | - | - |
|
5590302023FLED PMI SNAP-IN YLW PVC FREE |
1,689 |
|
Datasheet | 559 | Bulk | Active | LED | Yellow | - | - | DC | 5V | 15mA | Round | 0.25" (6.35mm) | 5mm, T-1 3/4 | Round with Domed Top | 8mcd | 583nm | 60° | Wire Leads - 6" (152.40mm) | - | - |
|
5586003023FLED PMI SNAP-IN BLUE CLR 468NM |
4,451 |
|
Datasheet | 558 | Bulk | Active | LED | Blue | Colorless | Clear | Vf (Typ), If (Max) | 3.3V | 30mA | Round | 0.16" (4.06mm) | 3mm, T-1 | Round with Domed Top | 520mcd | 468nm | 45° | Wire Leads - 6" (152.40mm) | - | - |
|
5593001027FLED PMI SNAP-IN RED/GRN PVC FREE |
3,120 |
|
Datasheet | 559 | Bulk | Active | LED | Green, Red | - | - | Vf (Typ), If (Max) | 2.1V Green, 1.8V Red | 30mA Green, 40mA Red | Round | 0.25" (6.35mm) | 5mm, T-1 3/4 | Round with Domed Top | 40mcd Green, 90mcd Red | 565nm Green, 660nm Red | 60° | Wire Leads - 14" (355.60mm) | - | - |
|
5580701007FLED PANEL IND RED SNAP-IN |
3,531 |
|
Datasheet | 558 | Bulk | Active | LED | Red | Colorless | Clear | Vf (Typ), If (Max) | 1.8V | 40mA | Round | 0.16" (4.06mm) | 3mm, T-1 | Round with Domed Top | 170mcd | 660nm | - | Wire Leads - 14" (355.60mm) | - | - |
|
5590202023FLED PMI SNAP-IN GRN PVC FREE |
1,698 |
|
Datasheet | 559 | Bulk | Active | LED | Green | - | - | DC | 5V | 15mA | Round | 0.25" (6.35mm) | 5mm, T-1 3/4 | Round with Domed Top | 8mcd | 565nm | 60° | Wire Leads - 6" (152.40mm) | - | - |
|
5580803003FLED PANEL IND BLU WHT DFF SNAPIN |
1,776 |
|
Datasheet | 558 | Bulk | Active | LED | Blue | Blue | Diffused | Vf (Typ), If (Max) | 3.2V | 30mA | Round | 0.16" (4.06mm) | 3mm, T-1 | Round with Domed Top | 57mcd | 468nm | 100° | Wire Leads - 6" (152.40mm) | - | - |
|
6823132131F12MM HR/R PMI-12VDC |
3,628 |
|
Datasheet | 682 | Bag | Active | LED | Red | Red | - | DC | 12V | 20mA | Round | 0.49" (12.45mm) | - | Round with Flat Top | 510mcd | - | - | Solder Lug | - | - |
|
6051111110FLED PNL IND 5MM RED PROTRUDING |
2,356 |
|
Datasheet | 605 | Bulk | Active | LED | Red | - | - | Vf (Typ), If (Max) | 2V | 15mA | Round | 0.25" (6.35mm) | 2.79mm Dia | Round with Domed Top | 38mcd | - | - | - | - | - |
