Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IF-2-24PWR XFMR SEMI-TORO 2VA TH |
236 |
|
Datasheet | IF | Bulk | Active | Semi-Toroidal | 115V, 230V | Parallel 12V, Series 24V | Parallel 170mA, Series 85mA | Dual | Dual | No | 2VA | Through Hole | PC Pin | 53.00mm L x 44.00mm W | 17.60mm | 4000Vrms | 0.29 lb (131.54 g) |
|
DP-241-7-12PWR XFMR LAMINATED 56VA CHAS MT |
123 |
|
Datasheet | Two-4-One™ | Box | Active | Laminated Core | 115V, 230V | 12.6V | 4A | Dual | Single | Yes | 56VA | Chassis Mount | Solder, Quick Connect | 93.70mm L x 49.20mm W | 57.80mm | 2500Vrms | 1.7 lbs (771.1 g) |
|
|
241-5-10PWR XFMR LAMINATED 12VA CHAS MT |
1,443 |
|
Datasheet | Two-4-One™ | Box | Active | Laminated Core | 115V | 10V | 1.2A | Single | Single | Yes | 12VA | Chassis Mount | Solder, Quick Connect | 71.40mm L x 36.30mm W | 42.80mm | 2500Vrms | 0.7 lb (317.51 g) |
|
A41-43-36PWR XFMR LAMINATED 43VA CHAS MT |
1,026 |
|
Datasheet | All-4-One™ | Box | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 2.4A, Series 1.2A | Dual | Dual | No | 43VA | Chassis Mount | Solder, Quick Connect | 79.40mm L x 54.40mm W | 68.20mm | 4000Vrms | 1.6 lbs (725.7 g) |
|
14A-56-36PWR XFMR LAMINATED 56VA TH |
1,041 |
|
Datasheet | One-4-All™ | Box | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 3.12A, Series 1.56A | Dual | Dual | No | 56VA | Through Hole | PC Pin | 76.20mm L x 63.50mm W | 46.00mm | 4000Vrms | 1.7 lbs (771.1 g) |
|
M4L-2-3PWR XFMR LAMINATED 300VA CHAS MT |
1,055 |
|
Datasheet | M4L | Bulk | Active | Laminated Core | 250V, 230V, 210V | 115V | 2.6A | Single, Multiple Taps | Single | No | 300VA | Chassis Mount | Terminal Block | 106.68mm L x 103.51mm W | 95.30mm | 4000Vrms | 7 lbs (3.2 kg) |
|
MPI-250-24PWR XFMR LAMINATED 250VA CHAS MT |
3,685 |
|
Datasheet | MPI | Bulk | Active | Laminated Core | 100V, 115V, 200V, 215V, 230V | Parallel 12V, Series 24V | Parallel 20.8A, Series 10.4A | Dual, Multiple Taps | Dual | No | 250VA | Chassis Mount | Terminal Block | 104.80mm L x 104.90mm W | 98.20mm | 4000Vrms | 6.8 lbs (3.1 kg) |
|
MPI-400-48PWR XFMR LAMINATED 400VA CHAS MT |
1,576 |
|
Datasheet | MPI | Bulk | Active | Laminated Core | 100V, 115V, 200V, 215V, 230V | Parallel 24V, Series 48V | Parallel 16.7A, Series 8.3A | Dual, Multiple Taps | Dual | No | 400VA | Chassis Mount | Terminal Block | 104.80mm L x 128.10mm W | 98.20mm | 4000Vrms | 9.9 lbs (4.5 kg) |
|
HPI-20PWR XFMR LAMINATED 2000VA CHAS |
2,767 |
|
Datasheet | HPI | Bulk | Active | Laminated Core | 115V, 230V | Parallel 115V, Series 230V | Parallel 17.4A, Series 8.7A | Dual, Multiple Taps | Dual | No | 2000VA | Chassis Mount | Terminal Block | 190.50mm L x 133.70mm W | 166.50mm | 4000Vrms | 41 lbs (18.6 kg) |
|
|
HPI-27PWR XFMR LAMINATED 2750VA CHAS |
2,988 |
|
Datasheet | HPI | Bulk | Active | Laminated Core | 115V, 230V | Parallel 115V, Series 230V | Parallel 24A, Series 12A | Dual, Multiple Taps | Dual | No | 2750VA | Chassis Mount | Terminal Block | 190.50mm L x 149.70mm W | 166.50mm | 4000Vrms | 48 lbs (21.8 kg) |
