DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
V7805W-500DC DC CONVERTER 5V 2.5W |
1,584 |
|
Datasheet | V78W-500 | 3-SIP Module | Bulk | Obsolete | Linear Regulator Replacement | 1 | 9V | 72V | 5V | - | - | - | 500mA | 2.5 W | - | ITE (Commercial) | OTP, SCP | -40°C ~ 85°C | 87% | - | - | Through Hole | - | - | - | - |
|
PUZ3-D48-S12-DDC DC CONVERTER 12V 3W |
4,806 |
|
Datasheet | PUZ3-D (3W) | 24-DIP Module, 8 Leads | Bulk | Not For New Designs | Isolated Module | 1 | 36V | 75V | 12V | - | - | - | 250mA | 3 W | 1.5 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | - | - |
|
PYBJ6-D12-S12-DDC DC CONVERTER 12V 6W |
2,025 |
|
Datasheet | PYBJ6 (6W) | 6-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 18V | 12V | - | - | - | 500mA | 6 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C | 84% | - | - | Through Hole | - | - | CB Scheme, IEC, UL | 62368-1 |
|
|
PYBJ6-D12-S15-DDC DC CONVERTER 15V 6W |
1,538 |
|
Datasheet | PYBJ6 (6W) | 6-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 400mA | 6 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C | 85% | - | - | Through Hole | - | - | CB Scheme, IEC, UL | 62368-1 |
|
PYBJ6-D24-S5-MDC DC CONVERTER 5V 6W |
4,930 |
|
Datasheet | PYBJ6 (6W) | 6-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 1.2A | 6 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C | 83% | - | - | Surface Mount | - | - | CB Scheme, IEC, UL | 62368-1 |
|
|
PUZ3-D24-D5-DDC DC CONVERTER +/-5V 3W |
3,916 |
|
Datasheet | PUZ3-D (3W) | 24-DIP Module, 8 Leads | Tube | Not For New Designs | Isolated Module | 2 | 18V | 36V | 5V | -5V | - | - | 300mA, 300mA | 3 W | 1.5 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 81% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
VHS1-S5-S9-SIPDC DC CONVERTER 9V 1W |
3,910 |
|
Datasheet | VHS1-SIP (1W) | 7-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 W | 6 kV | Medical | SCP | -40°C ~ 105°C | 79% | - | - | Through Hole | - | - | UL | 60950-1 |
|
PQC10-48-S24-ODC-DC ISOLATED, 10 W, 36~75 VDC |
2,066 |
|
Datasheet | PQC10-O (10W) | Sixteenth Brick | Tray | Not For New Designs | Isolated Module | 1 | 36V | 60V | 24V | - | - | - | 417mA | 10 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | Sixteenth Brick | - | - | 62368-1 |
|
PRMC1-D5-S15-SDC DC CONVERTER 15V 1W |
1,870 |
|
Datasheet | PRMC1-S (1W) | 8-SIP Module, 7 Leads | Bulk | Not For New Designs | Isolated Module | 1 | 4.5V | 9V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 77% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
|
PRMC1-D12-S15-SDC DC CONVERTER 15V 1W |
4,669 |
|
Datasheet | PRMC1-S (1W) | 8-SIP Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 81% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
