Heat Sinks
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Package Cooled | Attachment Method | Shape | Length | Width | Diameter | Fin Height | Power Dissipation @ Temperature Rise | Thermal Resistance @ Forced Air Flow | Thermal Resistance @ Natural | Material | Material Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
904-27-2-12-2-B-0HEATSINK 27X27X12MM PIN |
4,721 |
|
Datasheet | 904 | Box | Active | Top Mount | BGA | Push Pin | Square, Pin Fins | 1.063" (27.00mm) | 1.063" (27.00mm) | - | 0.457" (11.60mm) | - | 4.30°C/W @ 200 LFM | 12.90°C/W | Aluminum | Black Anodized |
|
1277094.00" WIDE X 12" FLATBACK HEATSI |
3,286 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 12.000" (304.80mm) | 4.000" (101.60mm) | - | 1.395" (35.43mm) | - | - | 0.85°C/W | Aluminum | - |
|
394-2ABHEATSINK 5.5X1.5X5" SSR/IGBT |
4,537 |
|
Datasheet | 394 | Bulk | Active | Top Mount, Extrusion | Power Modules | Bolt On | Rectangular, Fins | 5.500" (139.70mm) | 5.000" (127.00mm) | - | 1.500" (38.10mm) | - | 0.60°C/W @ 500 LFM | 1.50°C/W | Aluminum | Black Anodized |
|
1277554.00" WIDE X 36" FLATBACK HEATSI |
1,467 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 4.000" (101.60mm) | - | 1.395" (35.43mm) | - | - | 0.85°C/W | Aluminum | - |
|
1277646.00" WIDE X 36" FLATBACK HEATSI |
2,456 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 6.000" (152.40mm) | - | 1.600" (40.64mm) | - | - | 0.28°C/W | Aluminum | - |
|
122256HEATSINK 15837 PROFILE 12" |
2,225 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | Power Modules | Adhesive | Rectangular, Fins | 12.000" (304.80mm) | 7.000" (177.80mm) | - | 2.275" (57.78mm) | - | - | - | Aluminum | Unfinished |
|
12565512.25WX36" EXTRUSIO 19152 XX4471 |
3,214 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 12.250" (311.15mm) | - | 1.000" (25.40mm) | - | - | 0.33°C/W | Aluminum | - |
|
1256457WX36" EXTRUSION 15837 |
2,334 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 7.000" (177.80mm) | - | 2.275" (57.78mm) | - | - | 0.08°C/W | Aluminum | - |
|
1256597.55WX36" EXTRUSION 19832 |
2,603 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 7.550" (191.77mm) | - | 2.800" (71.12mm) | - | - | 0.09°C/W | Aluminum | - |
|
12547613.381WX36" EXTRUSION XX5429 |
3,386 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 36.000" (914.40mm) | 13.381" (339.88mm) | - | 1.312" (33.32mm) | - | - | 0.16°C/W | Aluminum | - |
