Heat Sinks
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Package Cooled | Attachment Method | Shape | Length | Width | Diameter | Fin Height | Power Dissipation @ Temperature Rise | Thermal Resistance @ Forced Air Flow | Thermal Resistance @ Natural | Material | Material Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1255325WX12" EXTRUSION 16565 XX5732 |
1,560 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | SCR | Press Fit | Rectangular, Fins | 12.000" (304.80mm) | 5.000" (127.00mm) | - | 2.500" (63.50mm) | - | - | 0.35°C/W | Aluminum | - |
|
HSF-55-35-Y-FFANSINK 12VDC 55X55X35.1MM |
3,999 |
|
Datasheet | HSF | Bulk | Active | Top Mount | BGA | Clip | Square, Fins | 2.165" (55.00mm) | 2.165" (55.00mm) | - | 1.382" (35.10mm) | - | - | 0.59°C/W | Aluminum Alloy | Black Anodized |
|
1254995X12" EXTRUSION 6542 XX1245 |
4,001 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | - | Bolt On | Rectangular, Fins | 12.000" (304.80mm) | 5.000" (127.00mm) | - | 5.000" (127.00mm) | - | - | 0.18°C/W | Aluminum | - |
|
1256374.702WX12" EXTRUSION 14264 |
1,689 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | - | Press Fit | Rectangular, Fins | 12.000" (304.80mm) | 4.702" (119.43mm) | - | 3.312" (84.13mm) | - | - | 0.45°C/W | Aluminum | - |
|
1255387WX12" EXTRUSION 16348 XX3559-2 |
2,791 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | SCR | Press Fit | Rectangular, Fins | 12.000" (304.80mm) | 7.000" (177.80mm) | - | 3.125" (79.38mm) | - | - | 0.21°C/W | Aluminum | - |
|
1255447WX12" EXTRUSION 16235 XX5733 |
2,106 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | SCR | Press Fit | Rectangular, Fins | 12.000" (304.80mm) | 7.000" (177.80mm) | - | 3.125" (79.38mm) | - | - | 0.22°C/W | Aluminum | - |
|
1255056.25WX12" EXTRUSION 16971 XX1541 |
2,059 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | - | Bolt On | Rectangular, Fins | 12.000" (304.80mm) | 6.250" (158.75mm) | - | 6.250" (158.75mm) | - | - | 0.15°C/W | Aluminum | - |
|
1255509.80WX12" SCR EXTRUSION XX5735 |
4,372 |
|
Datasheet | - | Box | Active | Board Level, Extrusion | SCR | Press Fit | Rectangular, Fins | 12.000" (304.80mm) | 9.800" (248.92mm) | - | 2.850" (72.39mm) | - | - | 0.18°C/W | Aluminum | - |
|
12768611.420" WIDE X 12" FLATBACK HEAT |
2,948 |
|
Datasheet | - | Box | Active | Top Mount, Extrusion | - | Adhesive | Rectangular, Fins | 12.000" (304.80mm) | 11.420" (290.07mm) | - | 2.559" (65.00mm) | - | - | 0.19°C/W | Aluminum | - |
|
658-60ABT4EHEATSINK CPU 27.9MM SQ W/ADH BLK |
1,626 |
|
Datasheet | 658 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 1.100" (27.94mm) | 1.100" (27.94mm) | - | 0.598" (15.20mm) | 2.5W @ 30°C | 2.00°C/W @ 500 LFM | - | Aluminum | Black Anodized |
