Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPB11CGVRA0SWITCH PUSH SPST-NO 0.4VA 20V |
1,728 |
|
Datasheet | TP | Bulk | Obsolete | Through Hole, Right Angle | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 65°C |
|
TPD11FGRA0SWITCH PUSHBUTTON SPDT 0.4VA 20V |
3,534 |
|
- |
TP | Bulk | Obsolete | Through Hole, Right Angle | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 65°C |
|
|
MPS103FRASWITCH PUSHBUTTON SPDT 3A 115V |
3,488 |
|
- |
MPS | Bulk | Obsolete | Through Hole, Right Angle | Standard | SPDT | On-Mom | 3A (AC) | 115 V | - | Plunger for Cap | No Marking | - | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -15°C ~ 70°C |
|
|
TPB11CGRAES2SWITCH PUSH SPST-NO 0.4VA 20V |
1,837 |
|
Datasheet | TP | Bulk | Obsolete | Through Hole, Right Angle | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Red | - | - | PC Pin | - | - | - | -30°C ~ 65°C |
|
|
TPB11CGPCES0SWITCH PUSH SPST-NO 0.4VA 20V |
1,720 |
|
Datasheet | TP | Bulk | Obsolete | Through Hole | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 65°C |
|
TPC11CGRA2SWITCH PUSH SPST-NO 0.4VA 20V |
2,089 |
|
Datasheet | TP | Bulk | Obsolete | Panel Mount, Right Angle, Rear | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Red | - | - | PC Pin | - | - | Circular - 4.83mm Dia | -30°C ~ 65°C |
|
TSPDF11FGRA0SWITCH PUSHBUTTON SPDT 0.4VA 20V |
4,286 |
|
Datasheet | TSP | Bulk | Obsolete | Through Hole, Right Angle | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger, Flush | No Marking | Black | - | - | PC Pin | - | Process Sealed | - | -30°C ~ 85°C |
|
|
TPB21RGRA0SWITCH PUSHBUTTON DPDT 0.4VA 20V |
2,165 |
|
Datasheet | TP | Bulk | Obsolete | Through Hole, Right Angle | Standard | DPDT | On-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 65°C |
|
TPCF13C0SWITCH PUSH SPST-NO 1A 125V |
4,965 |
|
- |
TP | Bulk | Obsolete | Panel Mount, Rear | Standard | SPST-NO | Off-Mom | 1A (AC/DC) | 125 V | 20 V | Round, Plunger, Flush | No Marking | Black | - | - | Solder Lug | - | - | Circular - 4.83mm Dia | -30°C ~ 65°C |
|
TPF13C0SWITCH PUSH SPST-NO 1A 125V |
1,331 |
|
Datasheet | TP | Bulk | Obsolete | Panel Mount, Rear | Standard | SPST-NO | Off-Mom | 1A (AC/DC) | 125 V | 20 V | Round, Plunger | No Marking | Black | - | - | Solder Lug | - | - | Circular - 6.35mm Dia | -30°C ~ 65°C |
