Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PF24-34PWR XFMR SEMI-TORO 24VA TH |
4,003 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 17V, Series 34V | Parallel 850mA, Series 430mA | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
PF24-10PWR XFMR SEMI-TORO 24VA TH |
3,199 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 5V, Series 10V | Parallel 4.8A, Series 2.4A | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
PF24-20PWR XFMR SEMI-TORO 24VA TH |
2,987 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 10V, Series 20V | Parallel 2.4A, Series 1.2A | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
PF24-30PWR XFMR SEMI-TORO 24VA TH |
4,338 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 15V, Series 30V | Parallel 1.6A, Series 800mA | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
3FL34-340PWR XFMR LAMINATED 12VA TH |
3,729 |
|
Datasheet | 3FL | Bulk | Obsolete | Laminated Core | 115V, 230V | Parallel 17V, Series 34V | Parallel 680mA, Series 340mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 63.50mm L x 50.80mm W | 27.05mm | 1500Vrms | - |
|
3FL12-950PWR XFMR LAMINATED 12VA TH |
4,631 |
|
Datasheet | 3FL | Bulk | Obsolete | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 1.9A, Series 950mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 63.50mm L x 50.80mm W | 27.05mm | 1500Vrms | - |
|
PF24-12PWR XFMR SEMI-TORO 24VA TH |
2,967 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 3.8A, Series 1.9A | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
PF24-16PWR XFMR SEMI-TORO 24VA TH |
3,945 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 8V, Series 16V | Parallel 3A, Series 1.5A | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
|
3FL20-600PWR XFMR LAMINATED 12VA TH |
1,825 |
|
Datasheet | 3FL | Bulk | Obsolete | Laminated Core | 115V, 230V | Parallel 10V, Series 20V | Parallel 1.2A, Series 600mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 63.50mm L x 50.80mm W | 27.05mm | 1500Vrms | - |
|
PF24-24PWR XFMR SEMI-TORO 24VA TH |
4,291 |
|
Datasheet | PF24 | Tube | Obsolete | Semi-Toroidal | 115V, 230V | Parallel 12V, Series 24V | Parallel 2A, Series 1A | Dual | Dual | No | 24VA | Through Hole | PC Pin | 72.00mm L x 58.00mm W | 31.80mm | 1500Vrms | - |
