Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MPI-900-48PWR XFMR LAMINATED 900VA CHAS MT |
2,253 |
|
Datasheet | MPI | Bulk | Active | Laminated Core | 100V, 115V, 200V, 215V, 230V | Parallel 24V, Series 48V | Parallel 37.5A, Series 18.8A | Dual, Multiple Taps | Dual | No | 900VA | Chassis Mount | Terminal Block | 133.30mm L x 139.70mm W | 117.80mm | 4000Vrms | 19.8 lbs (9 kg) |
|
HPI-12PWR XFMR LAMINATED 1250VA CHAS |
1,376 |
|
Datasheet | HPI | Bulk | Active | Laminated Core | 115V, 230V | Parallel 115V, Series 230V | Parallel 10.9A, Series 5.4A | Dual, Multiple Taps | Dual | No | 1250VA | Chassis Mount | Terminal Block | 179.30mm L x 129.60mm W | 154.90mm | 4000Vrms | 31 lbs (14.1 kg) |
|
16-100PWR XFMR LAMINATED 1600VA CHAS |
3,751 |
|
Datasheet | - | Box | Active | Laminated Core | 105V, 115V, 125V | Parallel 8V, Series 16V | Parallel 200A, Series 100A | Single, Multiple Taps | Single, Multiple Taps | Yes | 1600VA | Chassis Mount | Solder, Quick Connect | 190.50mm L x 190.50mm W | 162.00mm | 1500Vrms | 50 lbs (22.7 kg) |
|
PC-24-180PWR XFMR LAMINATED 4.4VA TH |
4,576 |
|
Datasheet | PC | Box | Active | Laminated Core | 115V | Parallel 12V, Series 24V | Parallel 360mA, Series 180mA | Single | Dual | No | 4.4VA | Through Hole | PC Pin | 41.30mm L x 31.80mm W | 34.92mm | 1500Vrms | 0.313 lb (141.97 g) |
|
PC-24-50PWR XFMR LAMINATED 1.2VA TH |
1,996 |
|
Datasheet | PC | Box | Active | Laminated Core | 115V | Parallel 12V, Series 24V | Parallel 100mA, Series 50mA | Single | Dual | No | 1.2VA | Through Hole | PC Pin | 34.90mm L x 28.60mm W | 30.15mm | 1500Vrms | - |
|
PC-40-30PWR XFMR LAMINATED 1.2VA TH |
4,834 |
|
Datasheet | PC | Box | Active | Laminated Core | 115V | Parallel 20V, Series 40V | Parallel 60mA, Series 30mA | Single | Dual | No | 1.2VA | Through Hole | PC Pin | 34.90mm L x 28.60mm W | 30.15mm | 1500Vrms | 0.188 lb (85.28 g) |
|
DST-2-36PWR XFMR LAMINATED 1.1VA TH |
3,384 |
|
Datasheet | DST | Box | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 60mA, Series 30mA | Dual | Dual | No | 1.1VA | Through Hole | PC Pin | 34.90mm L x 28.60mm W | 24.60mm | 2500Vrms | 0.17 lb (77.11 g) |
|
14A-5.0R-10PWR XFMR LAMINATED 5VA TH |
100 |
|
Datasheet | One-4-All™ | Bulk | Active | Laminated Core | 115V, 230V | Parallel 5V, Series 10V | Parallel 1A, Series 500mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.30mm L x 36.50mm W | 34.90mm | 4000Vrms | 0.37 lb (167.83 g) |
|
|
DST-4-48PWR XFMR LAMINATED 6VA TH |
4,807 |
|
Datasheet | DST | Bulk | Active | Laminated Core | 115V, 230V | Parallel 24V, Series 48V | Parallel 250mA, Series 125mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.30mm L x 33.30mm W | 33.30mm | 2500Vrms | 0.44 lb (199.58 g) |
|
LP-10-600PWR XFMR SEMI-TORO 6VA TH |
4,374 |
|
Datasheet | LP | Bulk | Active | Semi-Toroidal | 115V, 230V | Parallel 5V, Series 10V | Parallel 1.2A, Series 600mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 47.50mm L x 39.60mm W | 21.60mm | 1500Vrms | 0.438 lb (198.67 g) |
