DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PQB3-D12-S24-DDC DC CONVERTER 24V 3W |
1,667 |
|
Datasheet | PQB3-D (3W) | 24-DIP Module, 10 Leads | Bulk | Not For New Designs | Isolated Module | 1 | 9V | 18V | 24V | - | - | - | 125mA | 3 W | 1.5 kV | ITE (Commercial) | OCP, SCP | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
PYBE20-Q24-D9DC DC CONVERTER +/-9V 20W |
3,156 |
|
Datasheet | PYBE20 (20W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 2 | 9V | 36V | 9V | -9V | - | - | 1.111A, 1.111A | 20 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 60950-1 |
|
VPOL16A-12-SMTDC DC CONVERTER 0.75-5V 80W |
3,894 |
|
Datasheet | VPOL16A | 6-SMD Module | Cut Tape (CT) | Not For New Designs | Non-Isolated PoL Module | 1 | 9V | 14V | 0.75 ~ 5V | - | - | - | 16A | 80 W | - | ITE (Commercial) | Remote On/Off, OCP, OTP, SCP, UVLO | -40°C ~ 85°C | 94% | - | - | Surface Mount | - | Enable, Active High | - | - |
|
PDQE30-Q48-S5-DDC DC CONVERTER 5V 30W |
3,254 |
|
Datasheet | PDQE30-D (30W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 6A | 30 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | - | - | CE | - |
|
|
PDQE30-Q48-S15-DDC DC CONVERTER 15V 30W |
3,599 |
|
Datasheet | PDQE30-D (30W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 1 | 18V | 75V | 15V | - | - | - | 2A | 30 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | - | - | CE | - |
|
|
PDQE30-Q48-S24-DDC DC CONVERTER 24V 30W |
3,234 |
|
Datasheet | PDQE30-D (30W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 1.25A | 30 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | - | - | CE | - |
|
PDQE15-Q48-D12-DDC DC CONVERTER +/-12V 15W |
1,840 |
|
Datasheet | PDQE15-D (15W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 2 | 18V | 75V | 12V | -12V | - | - | 625mA, 625mA | 15 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
PDQE20-Q48-D15-DDC DC CONVERTER +/-15V 20W |
1,097 |
|
Datasheet | PDQE20-D (20W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 2 | 18V | 75V | 15V | -15V | - | - | 667mA, 667mA | 20 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
PRD15-Q24-S3-N-M-TRDC DC CONVERTER 3.3V 15W |
3,463 |
|
Datasheet | PRD15 (15W) | 6-SMD Module | Tape & Reel (TR) | Obsolete | Isolated Module | 1 | 9V | 36V | 3.3V | - | - | - | 4.5A | 15 W | 2 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 89% | - | - | Surface Mount | - | Enable, Active Low | - | - |
|
|
PRD15-Q48-S12-N-M-TRDC DC CONVERTER 12V 15W |
3,826 |
|
Datasheet | PRD15 (15W) | 6-SMD Module | Tape & Reel (TR) | Obsolete | Isolated Module | 1 | 18V | 75V | 12V | - | - | - | 1.3A | 15 W | 2.25 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 85% | - | - | Surface Mount | - | Enable, Active Low | - | - |
