DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
P7805-Q24-S15-SDC DC CONVERTER 15V 8W |
1,080 |
|
Datasheet | P7805-S | 3-SIP Module | Tube | Obsolete | Linear Regulator Replacement | 1 | 18V | 32V | 15V | - | - | - | 500mA | 8 W | - | ITE (Commercial) | OTP, SCP | -40°C ~ 85°C | 96% | - | - | Through Hole | - | - | EN | 55024; 55032 Class A |
|
P7805-Q24-S3-SDC DC CONVERTER 3.3V 2W |
1,383 |
|
Datasheet | P7805-S | 3-SIP Module | Tube | Obsolete | Linear Regulator Replacement | 1 | 4.75V | 28V | 3.3V | - | - | - | 500mA | 2 W | - | ITE (Commercial) | OTP, SCP | -40°C ~ 85°C | 91% | - | - | Through Hole | - | - | EN | 55024 |
|
PEP1-S5-S9-MDC DC CONVERTER 9V 1W |
2,238 |
|
Datasheet | PEP1-M (1W) | 12-SMD Module, 10 Leads | Tube | Not For New Designs | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 62368-1 |
|
|
PEP1-S5-S5-M-TRDC DC CONVERTER 5V 1W |
2,678 |
|
Datasheet | PEP1-M (1W) | 12-SMD Module, 10 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 82% | - | - | Surface Mount | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 62368-1 |
|
PDS1-S12-S12-DDC DC CONVERTER 12V 1W |
4,238 |
|
Datasheet | PDS1-D (1W) | 7-DIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 83mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 81% | - | - | Through Hole | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 60950-1 |
|
PDM1-S24-S12-SDC DC CONVERTER 12V 1W |
4,158 |
|
Datasheet | PDM1-S (1W) | 6-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 21.6V | 26.4V | 12V | - | - | - | 83mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 81% | - | - | Through Hole | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 60950-1; 61000-3-2; 61000-3-3 |
|
|
PDM1-S12-S24-SDC DC CONVERTER 24V 1W |
3,078 |
|
Datasheet | PDM1-S (1W) | 6-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 24V | - | - | - | 42mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 80% | - | - | Through Hole | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 60950-1 |
|
|
PDM1-S24-S3-SDC DC CONVERTER 3.3V 1W |
1,914 |
|
Datasheet | PDM1-S (1W) | 6-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 21.6V | 26.4V | 3.3V | - | - | - | 303mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 74% | - | - | Through Hole | - | - | - | - |
|
PEME2-S24-S3-SDC-DC 3KV ISOLATED, 2 W, 21.6~26 |
3,337 |
|
Datasheet | PEME2-S (2W) | 7-SIP Module, 4 Leads | Tube | Not For New Designs | Isolated Module | 1 | 21.6V | 26.4V | 3.3V | - | - | - | 400mA | 1.32 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 76% | - | - | Through Hole | - | - | CE, cURus | 62368-1 |
|
PESE2-S24-S9-M-TRDC-DC 3KV ISOLATED, 2 W, 21.6~26 |
4,628 |
|
Datasheet | PESE2-M (2W) | 8-SMD Module, 5 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 21.6V | 26.4V | 9V | - | - | - | 222mA | 1.998 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | - | - | CE | 62368-1 |
