DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MGFW304815DC DC CONVERTER +/-15V |
3,909 |
|
Datasheet | MGFW (30W) | 6-DIP Module | Box | Active | Isolated Module | 2 | 18V | 76V | 15V or 30V | -15V | - | - | 1A, 1A | - | 1.5 kV | ITE (Commercial) | Bridgeable, Remote On/Off, OCP | -40°C ~ 85°C (With Derating) | 87% | - | - | Through Hole | - | - | - | - |
.jpg)
|
MGFS404805DC DC CONVERTER 5V 40W |
2,229 |
|
Datasheet | MGFS (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 76V | 5V | - | - | - | 8A | 40 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | - | Enable, Active Low | CE, cURus, DEMKO | - |
|
MGFS400512DC DC CONVERTER 12V 30W |
430 |
|
Datasheet | MGFS (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 4.5V | 13V | 12V | - | - | - | 2.5A | 30 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 87% | - | - | Through Hole | - | Enable, Active Low | CE, cURus, DEMKO | - |
|
MGFS302405DC DC CONVERTER 5V |
161 |
|
Datasheet | MGFS (30W) | 6-DIP Module | Box | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 6A | - | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP | -40°C ~ 85°C (With Derating) | 90% | - | - | Through Hole | - | - | - | - |
|
BRNS6DC DC CONVERTER 0.6-5.5V |
555 |
|
Datasheet | BRNS | 17-SMD Module | Strip | Active | Non-Isolated PoL Module | 1 | 3V | 14.4V | 0.6 ~ 5.5V | - | - | - | 6A | - | - | ITE (Commercial) | Remote On/Off, OCP, OTP | -40°C ~ 85°C | 86% | - | - | Surface Mount | - | - | - | - |
|
MGS1R52412DC DC CONVERTER 12V |
302 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 130mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R5123R3DC DC CONVERTER 3.3V |
279 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 3.3V | - | - | - | 400mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 80% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R50505DC DC CONVERTER 5V |
219 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Tube | Active | Isolated Module | 1 | 4.5V | 9V | 5V | - | - | - | 300mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
|
MGW30515DC DC CONVERTER +/-15V 3W |
582 |
|
Datasheet | MGW (3W) | 6-DIP Module | Box | Active | Isolated Module | 2 | 4.5V | 9V | 15V | -15V | - | - | 100mA, 100mA | 3 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
|
MGXS1R52415DC DC CONVERTER 15V 1.5W |
269 |
|
Datasheet | MGX (1.5W) | 6-SIP Module, 4 Leads | Bulk | Active | Isolated Module | 1 | 6V | 60V | 15V | - | - | - | 100mA | 1.5 W | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
