DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MGW1R52412DC DC CONVERTER +/-12V 24V 1.6W |
1,167 |
|
Datasheet | MGW (1.5W) | 5-SIP Module | Box | Active | Isolated Module | 2 | 18V | 36V | 12V | -12V | - | - | 65mA, 65mA | 1.6 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
|
MGS1R5243R3DC DC CONVERTER 3.3V |
2,811 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 18V | 36V | 3.3V | - | - | - | 400mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 78% | - | - | Through Hole | - | - | - | - |
|
|
MGW1R51215DC DC CONVERTER +/-15V |
3,171 |
|
Datasheet | MGW (1.5W) | 5-SIP Module | Box | Active | Isolated Module | 2 | 9V | 18V | 15V | -15V | - | - | 50mA, 50mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C | 81% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R51215DC DC CONVERTER 15V |
3,938 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 100mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 84% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R52415DC DC CONVERTER 15V |
1,533 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 100mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 82% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R50515DC DC CONVERTER 15V |
3,461 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 4.5V | 9V | 15V | - | - | - | 100mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 84% | - | - | Through Hole | - | - | - | - |
|
|
MGW1R54812DC DC CONVERTER +/-12V |
3,897 |
|
Datasheet | MGW (1.5W) | 5-SIP Module | Tube | Active | Isolated Module | 2 | 36V | 76V | 12V | -12V | - | - | 65mA, 65mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C | 81% | - | - | Through Hole | - | - | - | - |
|
|
MGS1R51205DC DC CONVERTER 5V |
1,561 |
|
Datasheet | MGS (1.5W) | 4-SIP Module | Box | Active | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 300mA | - | 1.5 kV | ITE (Commercial) | OCP | -40°C ~ 85°C (With Derating) | 83% | - | - | Through Hole | - | - | - | - |
|
SUW1R52412BDC DC CONVERTER +/-12V 24V 1.6W |
4,799 |
|
Datasheet | SUW (1.5W) | 6-SMD Module | Box | Active | Isolated Module | 2 | 18V | 36V | 12V | -12V | - | - | 65mA, 65mA | 1.6 W | 500 V | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 75% | - | - | Surface Mount | - | - | - | - |
|
|
SUW1R51212BDC DC CONVERTER +/-12V 24V 1.6W |
2,582 |
|
Datasheet | SUW (1.5W) | 6-SMD Module | Box | Active | Isolated Module | 2 | 9V | 18V | 12V | -12V | - | - | 65mA, 65mA | 1.6 W | 500 V | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 75% | - | - | Surface Mount | - | - | - | - |
