Multiple Conductor Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Wire Gauge | Conductor Strand | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Shield Type | Length | Jacket Color | Ratings | Features | Voltage | Operating Temperature | Usage | Jacket (Insulation) Thickness | Conductor Insulation | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
M5362 SL005CABLE 4CON 20AWG SLATE SHLD 100' |
2,381 |
|
Datasheet | - | Spool | Active | Multi-Conductor | 4 | 20 AWG | 7/28 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.262" (6.65mm) | Foil, Braid | 100.0' (30.5m) | Slate | UL Style 2464 | Drain Wire, Rip Cord | 300 V | -20°C ~ 80°C | - | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
901805CY SL005CABLE 5COND 18AWG SLATE 100' |
4,995 |
|
Datasheet | Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 5 | 18 AWG | 19/30 | Copper, Bare | Thermoplastic Elastomer (TPE) | 0.387" (9.83mm) | - | 100.0' (30.5m) | Slate | - | - | 600 V | -30°C ~ 90°C | Industrial | 0.0500" (1.270mm) | Poly-Vinyl Chloride (PVC), Polyamide (PA), Nylon | - |
|
79056 SL005CABLE 2COND 26AWG SLATE 100' |
2,494 |
|
Datasheet | EcoFlex® | Spool | Active | Multi-Conductor | 2 | 26 AWG | 7/34 | Copper, Tinned | Polyphenylene Ether, Modified (mPPE) | 0.150" (3.81mm) | - | 100.0' (30.5m) | Slate | ISO 10993 | Biological Compatibility | 600 V | -40°C ~ 105°C | - | 0.0350" (0.889mm) | Polyphenylene Ether, Modified (mPPE) | - |
|
2460C SL002CABLE 2CON 22AWG SLATE SHLD 500' |
3,283 |
|
Datasheet | - | Spool | Active | Multi-Conductor | 2 | 22 AWG | Solid | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.126" (3.20mm) | Foil | 500.0' (152.4m) | Slate | - | Drain Wire | 300 V | -20°C ~ 75°C | Communication, Control | 0.0200" (0.508mm) | Polypropylene (PP) | - |
|
|
2460C SL022CABLE 2CON 22AWG SLATE SHLD 500' |
4,485 |
|
Datasheet | - | Spool | Active | Multi-Conductor | 2 | 22 AWG | Solid | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.126" (3.20mm) | Foil | 500.0' (152.4m) | Slate | - | Drain Wire | 300 V | -20°C ~ 75°C | Communication, Control | 0.0200" (0.508mm) | Polypropylene (PP) | - |
|
901604CY SL005CABLE 4CON 16AWG SLATE SHLD 100' |
1,009 |
|
Datasheet | Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 4 | 16 AWG | 26/30 | Copper, Bare | Thermoplastic Elastomer (TPE) | 0.384" (9.75mm) | Braid | 100.0' (30.5m) | Slate | - | - | 600 V | -30°C ~ 90°C | Industrial | 0.0500" (1.270mm) | Poly-Vinyl Chloride (PVC), Polyamide (PA), Nylon | - |
|
|
902005CY SL005CABLE 5CON 20AWG SLATE SHLD 100' |
4,629 |
|
Datasheet | Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 5 | 20 AWG | 10/30 | Copper, Bare | Thermoplastic Elastomer (TPE) | 0.341" (8.66mm) | Braid | 100.0' (30.5m) | Slate | - | - | 600 V | -30°C ~ 90°C | Industrial | 0.0450" (1.143mm) | Poly-Vinyl Chloride (PVC), Polyamide (PA), Nylon | - |
|
65005 SL005CABLE 5COND 20AWG SLATE 100' |
4,152 |
|
Datasheet | Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 5 | 20 AWG | 10/30 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.305" (7.75mm) | - | 100.0' (30.5m) | Slate | ISO 10993, UL Style 2587 | Biological Compatibility | 600 V | - | - | 0.0380" (0.965mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
2412C SL022CABLE 2CON 20AWG SLATE SHLD 500' |
1,875 |
|
Datasheet | - | Spool | Active | Multi-Conductor | 2 | 20 AWG | 7/28 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.184" (4.67mm) | Foil | 500.0' (152.4m) | Slate | - | Drain Wire | 300 V | -20°C ~ 75°C | Communication, Control | 0.0200" (0.508mm) | Polyethylene (PE) | - |
|
80015 SL005CABLE 3COND 22AWG SLATE 100' |
3,917 |
|
Datasheet | EcoFlex® PUR | Spool | Active | Multi-Conductor | 3 | 22 AWG | 19/34 | Copper, Tinned | Polyurethane (PU) | 0.180" (4.57mm) | - | 100.0' (30.5m) | Slate | - | - | 600 V | -50°C ~ 90°C | - | 0.0319" (0.810mm) | Polyphenylene Ether (PPE) | - |
