Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9007MS02S0121SWITCH LIMIT SPDT 6A 120V |
4,922 |
|
Datasheet | 9007 | Box | Active | SPDT | On-Mom | 6A (AC), 5A (DC) | 120 V | 28 V | Roller Plunger | Chassis Mount | Cable Leads | IP20 | - | - | - | - | - | - | - | -40°C ~ 104°C |
|
|
9007MS12S0300SWITCH LIMIT SPDT 6A 120V |
3,709 |
|
Datasheet | Square D 9007MS | Box | Active | SPDT | On-Mom | 6A (AC), 5A (DC) | 120 V | 28 V | Roller Plunger | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -40°C ~ 105°C |
|
|
9007MS09G0112SWITCH LIMIT 10A 240V |
3,954 |
|
Datasheet | MSC | Box | Active | - | - | 10A (AC) | 240 V | - | Spring, Rod | - | - | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -20°C ~ 105°C |
|
|
9007MS05S003182SWITCH LIMIT 10A 240V |
4,566 |
|
Datasheet | Square D 9007MS | Box | Active | - | - | 10A (AC) | 240 V | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
XCKD2528P16SWITCH LIMIT DPST 3A 240V |
1,917 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Lever, Roller | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
XCKP2149M12SWITCH LIMIT DPST 3A 240V |
4,212 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Side Rotary, Roller | Chassis Mount | Connector | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
XCKM106H7SWITCH LIMIT DPST 3A 240V |
1,530 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Spring, Cat Whisker | Chassis Mount | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
9007MS04G0054SWITCH LIMIT SPDT 0.1A 125V |
4,463 |
|
Datasheet | Square D 9007MS | Box | Active | SPDT | On-Mom | 100mA (AC), 30mA (DC) | 125 V | 28 V | Side Rotary - No Lever | Chassis Mount | Connector | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -40°C ~ 104°C |
|
XCKJ1167DSA8SWITCH LIMIT SPDT 3A 240V |
3,883 |
|
Datasheet | XCKJ | Box | Active | SPDT | On-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Roller Plunger | Chassis Mount | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
ZCMV41L03LMT SWTCH, BODY,NC+NO SLOW, M12 |
3,518 |
|
Datasheet | XC | Bulk | Active | 4PST-2NO/2NC | On-Mom, Off-Mom | 3A (AC), 1A (DC) | 24 V | 24 V | Without | Chassis Mount | Wire Leads | - | - | - | - | - | - | - | - | -40°C ~ 70°C |
