Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XCMD2517L1SWITCH LIMIT DPST 1.5A 240V |
4,471 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 1.5A (AC), 100mA (DC) | 240 V | 250 V | Ball Bearing Plunger | Chassis Mount | Cable Leads | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
9007MS02G0100SWITCH LIMIT SPDT 0.1A 125V |
3,250 |
|
Datasheet | Square D 9007MS | Box | Active | SPDT | On-Mom | 100mA (AC), 30mA (DC) | 125 V | 28 V | Roller Plunger | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -40°C ~ 104°C |
|
|
9007MS04S0180SWITCH LIMIT 10A 240V |
3,631 |
|
Datasheet | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
XCKD2128G11SWITCH LIMIT DPST 3A 240V |
3,992 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Lever, Roller | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
XCPR2518N12SWITCH LIMIT DPST 3A 240V |
1,997 |
|
Datasheet | XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Side Rotary, Roller | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
9007MS09S0506SWITCH LIMIT SPDT 6A 120V |
3,460 |
|
Datasheet | Square D 9007MS | Box | Active | SPDT | On-Mom | 6A (AC), 5A (DC) | 120 V | 28 V | Adjustable Plunger | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -40°C ~ 104°C |
|
|
9007CB34S1SWITCH SNAP ACTION DPDT 3A 120V |
3,672 |
|
Datasheet | 9007 | Box | Active | DPDT (DB/DM) | On-On | 3A (AC), 200mA (DC) | 120 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP20 | - | - | - | - | - | - | - | -29°C ~ 85°C |
|
|
9007MS03S0106SWITCH LIMIT SPDT 6A 120V |
2,982 |
|
Datasheet | Square D 9007MS | Box | Active | SPDT | On-Mom | 6A (AC), 5A (DC) | 120 V | 28 V | Roller Plunger | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -40°C ~ 104°C |
|
|
9007CP221SWITCH SNAP ACTION DPDT 3A 240V |
2,893 |
|
Datasheet | Square D 9007C | Box | Active | DPDT (DB/DM) | On-On | 3A (AC), 200mA (DC) | 240 V | 120 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP20 | - | - | - | - | - | - | - | -29°C ~ 85°C |
|
|
ZCKJ11DSAHSWITCH LIMIT 10A 240V |
4,519 |
|
Datasheet | - | Box | Active | - | - | 10A (AC) | 240 V | - | - | Chassis Mount | Cable Leads | - | - | - | - | - | - | - | - | - |
