Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LSXYAB3K2SWITCH SNAP ACTION SPDT 10A 120V |
2,930 |
|
Datasheet | LSX | Bulk | Obsolete | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Counterclockwise Operation Only | 46gfm | - | - | 15° | 5° | 60° | -40°C ~ 121°C |
|
LSJ1A-7MSWITCH SNAP ACTION SPDT 10A 120V |
1,909 |
|
Datasheet | HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Spring, Wire | Chassis Mount | Plug In | - | - | 141gf | - | - | 4.000" (102mm) | - | - | -12°C ~ 93°C |
|
|
8AS150SWITCH SEALED |
1,351 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
LSXA4L3-2CSWITCH SNAP ACTION DPDT 10A 120V |
3,039 |
|
Datasheet | LSX | Bulk | Obsolete | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Adjustable Roller | Chassis Mount | Screw Terminal | - | Nylon Roller, Front Mounted | 46gfm | - | - | 15° | 7° | 60° | -12°C ~ 121°C |
|
|
LSXA4L4-2CSWITCH SNAP ACTION DPDT 10A 120V |
2,143 |
|
Datasheet | LSX | Bulk | Obsolete | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Adjustable Roller | Chassis Mount | Screw Terminal | - | Nylon Roller, Front Mounted | 46gfm | - | - | 15° | 7° | 60° | -12°C ~ 121°C |
|
|
LSXM7N-1ASWITCH SNAP ACTION DPDT 10A 120V |
4,600 |
|
Datasheet | LSX | Bulk | Obsolete | DPDT (DB/DM) | Mom-Off-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Roller | Chassis Mount | Screw Terminal | - | Nylon Roller, Front Mounted | 46gfm | - | - | 18° | 10° | 57° | -1°C ~ 121°C |
|
LSU1ASWITCH SNAP ACTION SPDT 10A 120V |
3,044 |
|
Datasheet | HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Plug In | - | - | 46gfm | - | - | 5° | 3° | 70° | -12°C ~ 121°C |
|
|
LSU3KSWITCH SNAP ACTION SPDT 10A 120V |
3,513 |
|
Datasheet | HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | - | 46gfm | - | - | 5° | 3° | 70° | -12°C ~ 121°C |
|
DTV6-2RNSWITCH SNAP ACTION DPDT 10A 125V |
4,882 |
|
Datasheet | V6 | Bulk | Active | DPDT | On-Mom | 10A (AC), 300mA (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP66 - Dust Tight, Water Resistant | Actuator Seal Boot | 737 ~ 1673gf | - | 2.811" (71.4mm) | 0.110" (2.8mm) | 0.060" (1.5mm) | 0.125" (3.2mm) | -32°C ~ 71°C |
|
OP-AR62SWITCH SNAP ACTION SPDT 15A 125V |
2,497 |
|
Datasheet | OP | Bulk | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Side Rotary, Roller | Chassis Mount | Screw Terminal | - | - | 227 ~ 567gf | 113gf | - | 0.219" (5.6mm) | 0.007" (0.18mm) | 90° | - |
