Flat Ribbon Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Pitch | Length | Wire Gauge | Conductor Strand | Shielding | Jacket Color | Ribbon Thickness | Ribbon Width | Jacket (Insulation) Material | Voltage | Operating Temperature | Ratings | Features | Ratings | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3365/34 300CBL RIBN 34COND 0.05 GRAY 100' |
3,219 |
|
Datasheet | 3365 | Bulk | Discontinued at Digi-Key | Flat Cable | 34 | 0.050" (1.27mm) | 100.0' (30.48m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 1.700" (43.18mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Zippable |
|
3625/34SF 30MCBL RIBN 34COND 0.039 GRAY 98.4' |
1,295 |
|
Datasheet | 3625 | Bulk | Obsolete | Flat Cable | 34 | 0.039" (1.00mm) | 98.4' (30.00m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 1.339" (34.00mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Zippable |
|
HF100/24TP 100CBL RIBN 24COND TWIST PAIR 25' |
4,516 |
|
Datasheet | HF100 | Bulk | Active | Flat Twisted Pair | 24 (12 Pair Twisted) | 0.050" (1.27mm) | 25.0' (7.62m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Blue, White | 0.070" (1.78mm) | 1.200" (30.48mm) | Polyolefin (PO) | 150 V | - | - | -40°C ~ 105°C | UL Style 21008 | - |
|
SL8802/04-10DN5-00CBL RIBN 4COND 0.093 SILVER 50' |
1,148 |
|
Datasheet | SL8800 | Spool | Discontinued at Digi-Key | Flat Twin Axial | 4 (2 Pair) | 0.093" (2.37mm) Between Pairs | 50.0' (15.24m) | 30 AWG | Solid | Shielded | Silver | 0.035" (0.89mm) | 0.215" (5.45mm) | Polyolefin (PO) | 150 V | - | - | - | UL E42769 | - |
|
3601/15 100CBL RIBN 15COND 0.05 BLUE 10' |
2,525 |
|
Datasheet | 3601 | Bulk | Active | Flat Cable | 15 | 0.050" (1.27mm) | 10.0' (3.05m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Blue | 0.029" (0.74mm) | 0.750" (19.05mm) | Fluorinated Ethylene-Propylene (FEP) | 300 V | - | - | -55°C ~ 200°C | UL Style 20424 | - |
|
HF539/16CBL RIBN 16COND 0.05 GRAY 50' |
4,181 |
|
Datasheet | HF539 | Box | Discontinued at Digi-Key | Flat Cable | 16 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 19 Strands / 40 AWG | Unshielded | Gray | 0.035" (0.89mm) | 0.800" (20.32mm) | Polyolefin (PO) | 300 V | - | - | -40°C ~ 105°C | UL Style 21682 | Zippable |
|
2010/26 100SFCBL RIBN 26COND 0.05 WHITE 100' |
4,331 |
|
Datasheet | 2010 | Spool | Obsolete | Flat Cable | 26 | 0.050" (1.27mm) | 100.0' (30.48m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | White | 0.035" (0.89mm) | 1.300" (33.02mm) | Polyolefin (PO) | 30 V | - | - | -20°C ~ 105°C | UL Style 20930 | Splice Free, Zippable |
|
3659/16 100CBL RIBN 16COND 0.05 BLACK 50' |
3,329 |
|
Datasheet | 3659 | Bulk | Active | Flat Cable, Round Jacket | 16 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Black | - | 0.750" (19.05mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 20267 | Zippable |
|
HF365/64SFCBL RIBN 64COND 0.05 GRAY 25' |
4,110 |
|
Datasheet | HF365 | Box | Active | Flat Cable | 64 | 0.050" (1.27mm) | 25.0' (7.62m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 3.200" (81.28mm) | Polyolefin (PO) | 300 V | - | - | -40°C ~ 105°C | UL Style 21682 | Splice Free, Zippable |
|
HF625/08-100MCBL RIBN 8COND 0.039 GRAY 229.7' |
4,337 |
|
Datasheet | HF625 | Bulk | Discontinued at Digi-Key | Flat Cable | 8 | 0.039" (1.00mm) | 229.7' (70.00m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 0.315" (8.00mm) | Polyolefin (PO) | 300 V | - | - | -40°C ~ 105°C | UL Style 21682 | Zippable |
