Flat Ribbon Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Pitch | Length | Wire Gauge | Conductor Strand | Shielding | Jacket Color | Ribbon Thickness | Ribbon Width | Jacket (Insulation) Material | Voltage | Operating Temperature | Ratings | Features | Ratings | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
79100-075-4F1CBL RIBN 4COND 0.1 MULTIPLE 82' |
1,406 |
|
Datasheet | 79100 | Box | Obsolete | Flat Cable | 4 | 0.100" (2.54mm) | 82.0' (25.00m) | 19 AWG | 30 Strands / 33 AWG | Unshielded | Multiple | 0.100" (2.54mm) | 0.394" (10.00mm) | Poly-Vinyl Chloride (PVC) | - | - | - | - | UL E118773-K | - |
|
C3302/30 100CBL RIBN 30COND 0.05 MULTI 50' |
3,446 |
|
Datasheet | 3302 | Bulk | Discontinued at Digi-Key | Flat Cable | 30 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Multiple | 0.042" (1.07mm) | 1.500" (38.10mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 20462 | Zippable |
|
7700/14 100'SFCBL RIBN 14COND 0.025 SILVER 50' |
1,609 |
|
Datasheet | 7700 | Box | Discontinued at Digi-Key | Flat Cable | 14 | 0.025" (0.64mm) | 50.0' (15.24m) | 30 AWG | Solid | Unshielded | Silver | 0.030" (0.76mm) | 0.400" (10.16mm) | Polyolefin (PO) | 30 V | - | - | -20°C ~ 80°C | - | Splice Free |
|
3319/34 100CBL RIBN 34COND 0.05 BLACK 10' |
1,718 |
|
Datasheet | 3319 | Bulk | Active | Flat Cable | 34 | 0.050" (1.27mm) | 10.0' (3.05m) | 28 AWG | 19 Strands / 40 AWG | Unshielded | Black | 0.035" (0.89mm) | 1.700" (43.18mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Zippable |
|
HF100/14TPCBL RIBN 14COND TWIST PAIR 50' |
1,464 |
|
Datasheet | HF100 | Box | Active | Flat Twisted Pair | 14 (7 Pair Twisted) | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Blue, White | 0.070" (1.78mm) | 0.700" (17.78mm) | Polyolefin (PO) | 150 V | - | - | -40°C ~ 105°C | UL Style 21008 | - |
|
C3365/34 100SFCBL RIBN 34COND 0.05 GRAY 100' |
1,166 |
|
Datasheet | 3365 | Spool | Active | Flat Cable | 34 | 0.050" (1.27mm) | 100.0' (30.48m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 1.700" (43.18mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Splice Free, Zippable |
|
HF625/18-100MCBL RIBN 18COND 0.039 GRAY 98.4' |
2,133 |
|
Datasheet | HF625 | Bulk | Active | Flat Cable | 18 | 0.039" (1.00mm) | 98.4' (30.00m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Gray | 0.035" (0.89mm) | 0.709" (18.01mm) | Polyolefin (PO) | 300 V | - | - | -40°C ~ 105°C | UL Style 21682 | Zippable |
.jpg)
|
3754/68 300CBL RIBN 68COND 0.025 GRAY 50' |
3,206 |
|
Datasheet | 3754 | Bulk | Active | Flat Cable | 68 | 0.025" (0.64mm) | 50.0' (15.24m) | 30 AWG | 7 Strands / 38 AWG | Unshielded | Gray | 0.025" (0.64mm) | 1.700" (43.18mm) | Poly-Vinyl Chloride (PVC) | 30 V | - | - | -20°C ~ 105°C | UL Style 20596 | - |
|
3517/40 100CBL RIBN 40COND 0.05 GRAY 10' |
4,228 |
|
Datasheet | 3517 | Bulk | Active | Flat Cable, Flat Jacket | 40 | 0.050" (1.27mm) | 10.0' (3.05m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Gray | 0.110" (2.79mm) | 2.130" (54.10mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 80°C | UL Style 2912 | - |
|
2010/25 100SFCBL RIBN 25COND 0.05 WHITE 100' |
2,523 |
|
Datasheet | 2010 | Spool | Obsolete | Flat Cable | 25 | 0.050" (1.27mm) | 100.0' (30.48m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | White | 0.035" (0.89mm) | 1.250" (31.75mm) | Polyolefin (PO) | 30 V | - | - | -20°C ~ 105°C | UL Style 20930 | Splice Free, Zippable |
