DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Main Purpose | Outputs and Type | Voltage - Output | Current - Output | Voltage - Input | Regulator Topology | Frequency - Switching | Contents | Utilized IC / Part | Power - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MIC2224YML-EVEVAL BOARD FOR MIC2224 |
2,384 |
|
Datasheet | - | Box | Discontinued at Digi-Key | DC/DC, Step Down | 1 Non-Isolated Output | - | - | 600mA | 2.7V ~ 5.5V | Buck | 2MHz | Board(s) | MIC2224 |
|
MIC2253-06YML-EVEVAL BOARD FOR MIC2253 |
4,254 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | - | 3.5A | 2.5V ~ 10V | Boost | 1MHz | Board(s) | MIC2253 |
|
MIC23156-0YCS-EVEVAL BOARD FOR MIC23156 |
1,118 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 0.8V or 1V | 1.5A | 2.7V ~ 5.5V | Buck | 3MHz | Board(s) | MIC23156 |
|
MIC23303YML-EVEVAL BOARD FOR MIC23303 |
3,829 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 3A | 2.9V ~ 5.5V | Buck | 4MHz | Board(s) | MIC23303 |
|
MIC23450-AAAYML-EVEVAL BOARD FOR MIC23450 |
2,792 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 3 Non-Isolated Outputs | - | 1.2V, 1.5V, 1.8V | 2A, 2A, 2A | 2.7V ~ 5.5V | Buck | 3MHz | Board(s) | MIC23450 |
|
MIC23451-AAAYFL-EVEVAL BOARD FOR MIC23451 |
1,472 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 3 Non-Isolated Outputs | - | 1.2V, 1.5V, 1.8V | 2A, 2A, 2A | 2.7V ~ 5.5V | Buck | 3MHz | Board(s) | MIC23451 |
|
MIC33050-4YHL-EVEVAL BOARD FOR MIC33050 |
1,985 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V | 600mA | 2.7V ~ 5.5V | Buck | 4MHz | Board(s) | MIC33050 |
|
MIC33050-GYHL-EVEVAL BOARD FOR MIC33050 |
4,508 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 600mA | 2.7V ~ 5.5V | Buck | 4MHz | Board(s) | MIC33050 |
|
MIC33153-4YHJ-EVEVAL BOARD FOR MIC33153 |
3,586 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V | 1.2A | 2.7V ~ 5.5V | Buck | 4MHz | Board(s) | MIC33153 |
|
MIC33153YHJ-EVEVAL BOARD FOR MIC33153 |
3,407 |
|
Datasheet | HyperLight Load® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 1.2A | 2.7V ~ 5.5V | Buck | 4MHz | Board(s) | MIC33153 |
