Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ACM-31-222M-TCMC 200MA 2LN 2.2K OHM SMD |
30,076 |
|
Datasheet | Horizontal, 4 PC Pad | Signal Line | 2 | 2.2 kOhms @ 100 MHz | - | 200mA | 1.2Ohm | 50V | - | -40°C ~ 85°C | - | - | - | - | - |
|
ACM-0603-251-TCMC 400MA 2LN 250 OHM SMD |
3,539 |
|
Datasheet | Horizontal, 4 PC Pad | Signal Line | 2 | 250 Ohms @ 100 MHz | - | 400mA | 280mOhm | 50V | - | -40°C ~ 85°C | - | - | - | - | - |
|
ACMP-Q2012-900-TCMC 400MA 2LN 90OHM SMD AEC-Q200 |
6,913 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 90 Ohms @ 100 MHz | - | 400mA | 300mOhm | 50V | - | -55°C ~ 125°C | AEC-Q200 | - | - | - | - |
|
|
ACM-0603-900-TCMC 500MA 2LN 90 OHM SMD |
1,157 |
|
Datasheet | Horizontal, 4 PC Pad | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 500mA | 145mOhm | 50V | - | -40°C ~ 85°C | - | - | - | - | - |
|
ACMP-5025-101-TCMC 6.5A 2LN 100 OHM SMD |
7,447 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 100 Ohms @ 100 MHz | - | 6.5A | 9mOhm | 50V | - | -40°C ~ 125°C | - | - | - | - | - |
|
|
ACMP-5025-251-TCMC 5A 2LN 250 OHM SMD |
2,411 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 250 Ohms @ 100 MHz | - | 5A | 14mOhm | 50V | - | -40°C ~ 125°C | - | - | - | - | - |
|
|
ACMP-5045-302-TCMC 500MA 2LN 3K OHM SMD |
4,896 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 3 kOhms @ 100 MHz | - | 500mA | 300mOhm | 50V | - | -40°C ~ 125°C | - | - | - | - | - |
|
|
ACMP-9050-222-TCMC 2.5A 2LN 2.2K OHM SMD |
1,929 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 2.2 kOhms @ 100 MHz | - | 2.5A | 60mOhm | 125V | - | -40°C ~ 125°C | - | - | - | - | - |
|
ACMP-Q7040-102-TCMC 3A 2LN 1.02KOHM SMD AEC-Q200 |
4,219 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 1.02 kOhms @ 100 MHz | - | 3A | 17mOhm | 80V | - | -40°C ~ 125°C | AEC-Q200 | - | - | - | - |
|
|
ACMP-Q1260-102-TCMC 7A 2LN 1K OHM SMD AEC-Q200 |
974 |
|
Datasheet | Horizontal, 4 PC Pad | Power Line | 2 | 1 kOhms @ 100 MHz | - | 7A | 8mOhm | 80V | - | -40°C ~ 125°C | AEC-Q200 | - | - | - | - |
