Heat Sinks
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Package Cooled | Attachment Method | Shape | Length | Width | Diameter | Fin Height | Power Dissipation @ Temperature Rise | Thermal Resistance @ Forced Air Flow | Thermal Resistance @ Natural | Material | Material Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ATS-H1-179-C3-R0HEATSINK 35X35X30MM R-TAB T412 |
2,449 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.378" (35.00mm) | 1.378" (35.00mm) | - | 1.181" (30.00mm) | - | 4.07°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-H1-54-C2-R0HEATSINK 30X30X35MM L-TAB T766 |
1,005 |
|
Datasheet | pushPIN™ | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.181" (30.00mm) | 1.181" (30.00mm) | - | 1.378" (35.00mm) | - | 7.00°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-H1-84-C2-R0HEATSINK 30X30X35MM R-TAB T766 |
4,680 |
|
Datasheet | pushPIN™ | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.181" (30.00mm) | 1.181" (30.00mm) | - | 1.378" (35.00mm) | - | 7.00°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-14F-42-C1-R0HEATSINK 57.9X60.96X22.86MM |
3,384 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Rectangular, Fins | 2.280" (57.90mm) | 2.400" (60.96mm) | - | 0.900" (22.86mm) | - | 7.30°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-08G-42-C1-R0HEATSINK 57.9X60.96X22.86MM |
1,883 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Rectangular, Fins | 2.280" (57.90mm) | 2.400" (60.96mm) | - | 0.900" (22.86mm) | - | 7.30°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-P1-41-C3-R0HEATSINK 57.9X60.96X17.78MM T412 |
2,261 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Rectangular, Fins | 2.280" (57.90mm) | 2.400" (60.96mm) | - | 0.700" (17.78mm) | - | 10.07°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-P2-27-C1-R0HEATSINK 70X70X12.7MM XCUT |
4,658 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 2.756" (70.00mm) | 2.756" (70.00mm) | - | 0.500" (12.70mm) | - | 12.23°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-55400W-C0-R0HEATSINK 40X40X24.5MM W/OUT TIM |
3,506 |
|
- |
- | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Not Included) | Square, Pin Fins | 1.575" (40.00mm) | 1.575" (40.00mm) | - | 0.965" (24.50mm) | - | 2.60°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
ATS-H1-179-C2-R0HEATSINK 35X35X30MM R-TAB T766 |
2,555 |
|
Datasheet | pushPIN™ | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.378" (35.00mm) | 1.378" (35.00mm) | - | 1.181" (30.00mm) | - | 3.93°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-H1-126-C3-R0HEATSINK 54X54X15MM XCUT T412 |
1,261 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 2.126" (54.00mm) | 2.126" (54.00mm) | - | 0.590" (15.00mm) | - | 5.54°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
ATS-H1-204-C2-R0HEATSINK 54X54X12MM XCUT T766 |
1,637 |
|
Datasheet | pushPIN™ | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 2.126" (54.00mm) | 2.126" (54.00mm) | - | 0.472" (12.00mm) | - | 7.43°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
APR45-45-28CB/A01HEATSINK FORGED BLK ANO TOP MNT |
3,405 |
|
Datasheet | APR | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 1.756" (44.60mm) | 1.756" (44.60mm) | - | 1.087" (27.60mm) | - | 1.65°C/W @ 200 LFM | 6.60°C/W | Aluminum Alloy | Black Anodized |
|
|
APR45-45-33CB/A01HEATSINK FORGED BLK ANO TOP MNT |
3,112 |
|
Datasheet | APR | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 1.756" (44.60mm) | 1.756" (44.60mm) | - | 1.283" (32.60mm) | - | 1.41°C/W @ 200 LFM | 6.26°C/W | Aluminum Alloy | Black Anodized |
|
|
ATS-H1-54-C3-R0HEATSINK 30X30X35MM L-TAB T412 |
4,347 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.181" (30.00mm) | 1.181" (30.00mm) | - | 1.378" (35.00mm) | - | 7.19°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-H1-84-C3-R0HEATSINK 30X30X35MM R-TAB T412 |
3,401 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.181" (30.00mm) | 1.181" (30.00mm) | - | 1.378" (35.00mm) | - | 7.19°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-52325P-C0-R0HEATSINK 32.5X32.5X17.5MM NO TIM |
2,963 |
|
- |
maxiFLOW | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Not Included) | Square, Angled Fins | 1.280" (32.51mm) | 1.280" (32.51mm) | - | 0.689" (17.50mm) | - | 2.70°C/W @ 200 LFM | - | Aluminum | Blue Anodized |
|
ATS-H1-183-C2-R0HEATSINK 40X40X20MM R-TAB T766 |
3,611 |
|
Datasheet | pushPIN™ | Tray | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 1.575" (40.00mm) | 1.575" (40.00mm) | - | 0.790" (20.00mm) | - | 5.37°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
CE-OMNI-38HEATSINK CER TO-220 TO-247 |
4,167 |
|
Datasheet | - | Tray | Active | Board Level, Vertical | TO-220, TO-247 | Solderable Feet | Rectangular, Fins | 0.803" (20.40mm) | 1.339" (34.00mm) | - | 1.512" (38.40mm) | - | 3.80°C/W @ 200 LFM | 7.00°C/W | Ceramic | - |
|
ATS-20E-111-C3-R1HEATSINK 60.00MM X 60.00MM ALUM |
1,003 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 2.362" (60.00mm) | 2.362" (60.00mm) | - | 0.374" (9.50mm) | - | 26.82°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
|
|
ATS-21E-111-C3-R1HEATSINK 60.00MM X 60.00MM ALUM |
3,516 |
|
Datasheet | pushPIN™ | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Push Pin | Square, Fins | 2.362" (60.00mm) | 2.362" (60.00mm) | - | 0.374" (9.50mm) | - | 26.82°C/W @ 100 LFM | - | Aluminum | Blue Anodized |
