Test Points
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Mounting Type | Color | Hole Diameter | Size / Dimension | Height | Plating | Material - Insulation | Material - Body |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1040PC TEST POINT SLOTTED |
39,621 |
|
Datasheet | - | Bulk | Active | PC Test Point, Slotted | Through Hole | - | 0.039" (1.00mm) | 0.275" L x 0.110" W (6.99mm x 2.79mm) | - | Tin | No Insulation | Brass |
|
|
5021PC TEST POINT LOW PROFILE |
39,310 |
|
Datasheet | THM | Bulk | Active | PC Test Point, Low Profile | Through Hole | - | 0.040" (1.02mm) | 0.100" Dia (2.54mm) | 0.100" (2.54mm) | Silver | No Insulation | Phosphor Bronze |
|
4952PC TEST POINT LOOP |
41,098 |
|
Datasheet | - | Bulk | Active | PC Test Point, Loop | Through Hole | - | 0.047" (1.19mm) | 0.248" L x 0.118" W (6.30mm x 3.00mm) | - | Tin | No Insulation | Brass |
|
5020PC TEST POINT LOW PROFILE |
19,979 |
|
Datasheet | THM | Bulk | Active | PC Test Point, Low Profile | Through Hole | - | 0.040" (1.02mm) | 0.094" Dia (2.39mm) | 0.200" (5.08mm) | Silver | No Insulation | Phosphor Bronze |
|
1030PC TEST POINT SLOTTED |
42,806 |
|
Datasheet | - | Bulk | Active | PC Test Point, Slotted | Through Hole | - | 0.035" (0.89mm) | 0.114" L x 0.075" W (2.90mm x 1.91mm) | - | Tin | No Insulation | Brass |
|
5029PC TEST POINT MINIATURE |
1,822 |
|
Datasheet | - | Tape & Reel (TR) | Active | PC Test Point, Miniature | Surface Mount | - | - | 0.150" L x 0.080" W (3.81mm x 2.03mm) | 0.090" (2.29mm) | Silver | No Insulation | Phosphor Bronze |
|
5019PC TEST POINT MINIATURE |
160,416 |
|
Datasheet | - | Tape & Reel (TR) | Active | PC Test Point, Miniature | Surface Mount | - | - | 0.150" L x 0.080" W (3.81mm x 2.03mm) | 0.090" (2.29mm) | Silver | No Insulation | Phosphor Bronze |
|
5002PC TEST POINT MINIATURE WHITE |
290,821 |
|
Datasheet | THM | Bulk | Active | PC Test Point, Miniature | Through Hole | White | 0.040" (1.02mm) | 0.100" Dia x 0.180" L (2.54mm x 4.57mm) | - | Silver | Nylon 46, UL 94V-0 | Phosphor Bronze |
|
|
5001PC TEST POINT MINIATURE BLACK |
214,046 |
|
Datasheet | THM | Bulk | Active | PC Test Point, Miniature | Through Hole | Black | 0.040" (1.02mm) | 0.100" Dia x 0.180" L (2.54mm x 4.57mm) | - | Silver | Nylon 46, UL 94V-0 | Phosphor Bronze |
|
|
5084PC TEST POINT MINIATURE |
188,512 |
|
Datasheet | - | Tape & Reel (TR) | Active | PC Test Point, Miniature | Surface Mount | - | - | 0.105" L x 0.040" W (2.67mm x 1.02mm) | 0.060" (1.52mm) | Tin | No Insulation | Phosphor Bronze |
