Slide Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Contact Timing | Switch Function | Current Rating (Amps) | Voltage Rating - DC | Actuator Type | Actuator Length | Contact Material | Contact Finish | Mounting Type | Termination Style | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
48ASSP3S6M7RBTSWITCH SLIDE SPDT 0.4VA 20V |
3,821 |
|
Datasheet | 48A | Bulk | Active | SPDT | Not Specified | On-Off-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 12.32mm | Copper Alloy | Gold | Through Hole, Right Angle, Vertical | PC Pin | Epoxy Sealed Terminals |
|
|
LSU11-230101A3SWITCH SLIDE DP3T 11A 125V |
1,747 |
|
Datasheet | LSU, LAMB | Bulk | Active | DP3T | Non-Shorting (BBM) | On-On-On | 11A (AC) | 125 V | - | Standard | 3.00mm | Silver Alloy | - | Panel Mount | PC Pin | - |
|
|
1437579-6SWITCH SLIDE SPDTX2 0.4VA 20V |
4,273 |
|
Datasheet | TSS | Bulk | Obsolete | SPDT x 2 | Non-Shorting (BBM) | On-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 2.79mm | Copper | Gold | Through Hole, Right Angle | PC Pin | Epoxy Sealed Terminals |
|
|
4-1825010-6SWITCH SLIDE 6PDT 300MA 115V |
3,125 |
|
Datasheet | ASE | Bulk | Obsolete | 6PDT | Shorting (MBB) | On-On | 300mA (AC) | 115 V | - | Standard | 5.82mm | Copper Alloy | Silver | Surface Mount, Right Angle | Gull Wing | - |
|
GF-326-0189SWITCH SLIDE DPDT 3A 125V |
1,804 |
|
Datasheet | GF | Bulk | Active | DPDT | Not Specified | On-On | 3A (AC), 500mA (DC) | 125 V | 125 V | Push-Pull | 1.65mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
|
G-2011-0041SWITCH SLIDE SPST 8A 125V |
2,649 |
|
Datasheet | 2000 | Bulk | Active | SPST | Not Specified | On-Off | 8A (AC) | 125 V | - | Standard | 6.60mm | Copper | Silver | Panel Mount, Snap-In | Quick Connect - 0.250" (6.3mm) | White Actuator and Housing |
|
|
G-2011-0039SWITCH SLIDE SPST 13A 125V |
2,831 |
|
Datasheet | 2000 | Bulk | Active | SPST | Not Specified | On-Off | 13A (AC) | 125 V | - | Standard | 10.29mm | Copper | Silver | Panel Mount, Snap-In | Quick Connect - 0.250" (6.3mm) | Red Actuator and Housing |
|
L104031MS02BESWITCH SLIDE SP4T 0.4VA 20V |
1,210 |
|
Datasheet | L | Bulk | Active | SP4T | Not Specified | On-On-On-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 9.53mm | Copper | Gold | Through Hole | PC Pin | Epoxy Sealed Terminals |
|
|
L203011MS02BESWITCH SLIDE DP3T 0.4VA 20V |
4,559 |
|
Datasheet | L | Bulk | Obsolete | DP3T | Not Specified | On-On-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 5.08mm | Copper | Gold | Through Hole | PC Pin | Epoxy Sealed Terminals |
|
LP22C21T203QSWITCH SLIDE DPDT 6A 125V |
2,164 |
|
Datasheet | LP | Bulk | Obsolete | DPDT | Not Specified | On-On | 6A (AC/DC) | 125 V | 28 V | Snap on Cap | 9.55mm | Copper | Silver | Panel Mount, Snap-In | Solder Lug | - |
|
LP82C21T203DQSWITCH SLIDE DPDT 11A 125V |
4,143 |
|
Datasheet | LP | Bulk | Obsolete | DPDT | Not Specified | On-On | 11A (AC) | 125 V | - | Snap on Cap | 9.55mm | Copper | Silver | Panel Mount, Snap-In | Solder Lug | On-Off Marking on Housing |
|
|
TS01AKESWITCH SLIDE SPDT 0.4VA 20V |
1,223 |
|
Datasheet | TS | Bulk | Obsolete | SPDT | Not Specified | On-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 3.10mm | Copper Alloy | Gold | Through Hole, Right Angle | PC Pin | Epoxy Sealed Terminals |
|
|
TS01ALESWITCH SLIDE SPDT 3A 120V |
4,689 |
|
Datasheet | TS | Bulk | Obsolete | SPDT | Not Specified | On-On | 3A (AC/DC) | 120 V | 28 V | Standard | 3.10mm | Silver (Ag) | Gold | Through Hole, Right Angle | PC Pin | Epoxy Sealed Terminals |
|
|
TS01AMESWITCH SLIDE SPDT 3A 120V |
2,775 |
|
Datasheet | TS | Bulk | Obsolete | SPDT | Not Specified | On-On | 3A (AC/DC) | 120 V | 28 V | Standard | 3.10mm | Silver (Ag) | Silver | Through Hole, Right Angle | PC Pin | Epoxy Sealed Terminals |
|
TS01CBFSWITCH SLIDE SPDT 0.4VA 20V |
2,809 |
|
Datasheet | TS | Bulk | Obsolete | SPDT | Not Specified | On-On | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 3.10mm | Copper Alloy | Gold | Through Hole | PC Pin | Epoxy Sealed Terminals, RTV Rubber Seal |
|
|
TS01CGFSWITCH SLIDE SPDT 3A 120V |
4,720 |
|
Datasheet | TS | Bulk | Obsolete | SPDT | Not Specified | On-On | 3A (AC/DC) | 120 V | 28 V | Standard | 3.10mm | Silver (Ag) | Gold | Through Hole | PC Pin | Epoxy Sealed Terminals, RTV Rubber Seal |
|
|
TS02CKESWITCH SLIDE SPST 0.4VA 20V |
2,172 |
|
Datasheet | TS | Bulk | Obsolete | SPST | Not Specified | On-Off | 0.4VA (AC/DC) | 20 V | 20 V | Standard | 3.10mm | Copper Alloy | Gold | Through Hole | PC Pin | Epoxy Sealed Terminals |
|
1203M2S3V3ME2SWITCH SLIDE DPDT 6A 120V |
3,700 |
|
Datasheet | 1000 | Bulk | Obsolete | DPDT | Not Specified | On-Off-On | 6A (AC/DC) | 120 V | 28 V | Standard | 4.72mm | Copper | Silver | Through Hole | PC Pin | Black Actuator, Epoxy Sealed Terminals |
|
|
1201M2S3V3LE2SWITCH SLIDE DPDT 6A 120V |
2,986 |
|
Datasheet | 1000 | Bulk | Obsolete | DPDT | Not Specified | On-On | 6A (AC/DC) | 120 V | 28 V | Standard | 4.72mm | Copper | Gold | Through Hole | PC Pin | Black Actuator, Epoxy Sealed Terminals |
|
|
1201M2S3AME2SWITCH SLIDE DPDT 6A 120V |
2,832 |
|
Datasheet | 1000 | Bulk | Obsolete | DPDT | Not Specified | On-On | 6A (AC/DC) | 120 V | 28 V | Standard | 4.72mm | Copper | Silver | Through Hole, Right Angle | PC Pin | Black Actuator, Epoxy Sealed Terminals |
