Rocker Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Color - Actuator/Cap | Actuator Marking | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
300AWSP3J5BLKM2QESWITCH ROCKER 3PDT 5A 120V |
3,070 |
|
Datasheet | 300A | Bulk | Active | Panel Mount, Flange | 3PDT | On-Off-On | 5A (AC/DC) | 120 V | 28 V | Concave (Standard V) | Black | No Marking | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Epoxy Sealed Terminals | Rectangular - 13.14mm x 7.20mm | -30°C ~ 85°C | - |
|
|
300SP4J2GRYM2RESWITCH ROCKER SPDT 0.4VA 20V |
4,016 |
|
Datasheet | 300 | Bulk | Active | Through Hole | SPDT | Mom-Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Paddle | Gray | No Marking | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -30°C ~ 85°C | - |
|
RR3405CLREDSWITCH ROCKER SPDT 10A 125V |
4,313 |
|
Datasheet | RR3405 | Bulk | Active | Panel Mount, Threaded Body with Nut | SPDT | On-On | 10A (AC) | 125 V | - | Paddle - Illuminated | Black | No Marking | LED, Red | 2 VDC | Solder Lug | - | - | Circular - 18.00mm Dia | - | - |
|
|
300SP3J1BLKM6RESWITCH ROCKER SPDT 0.4VA 20V |
2,950 |
|
Datasheet | 300 | Tray | Active | Through Hole, Right Angle | SPDT | On-Off-On | 0.4VA (AC/DC) | 20 V | 20 V | Concave (Standard V) | Black | No Marking | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -30°C ~ 85°C | - |
|
|
400MSP3R6BLKM6RESWITCH ROCKER SPDT 0.4VA 20V |
3,550 |
|
Datasheet | 400 | Tray | Active | Through Hole, Right Angle | SPDT | On-Off-On | 0.4VA (AC/DC) | 20 V | 20 V | Concave (Curved) | Black | No Marking | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -30°C ~ 85°C | cULus |
|
|
400MSP2R6BLKM6QESWITCH ROCKER SPDT 3A 120V |
2,165 |
|
Datasheet | 400 | Bulk | Active | Through Hole, Right Angle | SPDT | On-Mom | 3A (AC/DC) | 120 V | 28 V | Concave (Curved) | Black | No Marking | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -30°C ~ 85°C | cULus |
|
|
300DP1J6BLKM2QESWITCH ROCKER DPDT 5A 120V |
3,176 |
|
Datasheet | 300 | Bulk | Active | Through Hole | DPDT | On-On | 5A (AC/DC) | 120 V | 28 V | Paddle | Black | No Marking | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -30°C ~ 85°C | - |
|
|
300DP1R11BLKM1QESWITCH ROCKER DPDT 5A 120V |
4,383 |
|
Datasheet | 300 | Bulk | Active | Panel Mount, Flange | DPDT | On-On | 5A (AC/DC) | 120 V | 28 V | Concave (Standard V) | Black | No Marking | - | - | Solder Lug | - | Epoxy Sealed Terminals | Rectangular - 12.78mm x 12.52mm | -30°C ~ 85°C | - |
|
|
300DP1R16WHTM1QESWITCH ROCKER DPDT 5A 120V |
3,390 |
|
Datasheet | 300 | Bulk | Active | Panel Mount, Flange | DPDT | On-On | 5A (AC/DC) | 120 V | 28 V | Paddle | White | No Marking | - | - | Solder Lug | - | Epoxy Sealed Terminals | Rectangular - 12.78mm x 12.52mm | -30°C ~ 85°C | - |
|
|
300DP1R2BLKM1QESWITCH ROCKER DPDT 5A 120V |
2,802 |
|
Datasheet | 300 | Bulk | Active | Panel Mount, Flange | DPDT | On-On | 5A (AC/DC) | 120 V | 28 V | Paddle | Black | No Marking | - | - | Solder Lug | - | Epoxy Sealed Terminals | Rectangular - 17.96mm x 10.62mm | -30°C ~ 85°C | - |
