RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R570113000IC RF SWITCH SPDT 12.4GHZ MODULE |
2,573 |
|
Datasheet | - | Module | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
.jpg)
|
R516431100IC RF SWITCH |
3,806 |
|
Datasheet | * | - | Strip | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R570863100IC RF SWITCH SPDT 40GHZ MODULE |
3,141 |
|
Datasheet | - | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 40GHz | 50dB (min) | 0.8dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R591362440IC RF SWITCH SP4T 6GHZ MODULE |
3,504 |
|
Datasheet | - | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 6GHz | 70dB (min) | 0.3dB (max) | 6GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R577342037IC RF SWITCH DPDT 3GHZ |
3,201 |
|
Datasheet | DPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | DPDT | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R599312000IC RF SWITCH SP8T |
3,443 |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP8T | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R599311000IC RF SWITCH SP3T/SP4T/SP5T/SP6T |
4,749 |
|
Datasheet | SPnT | Module | Bulk | Active | General Purpose | - | SP3T, SP4T, SP5T, SP6T | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R599308000IC RF SWITCH SP3T/SP4T/SP5T/SP6T |
4,416 |
|
Datasheet | SPnT | - | Bulk | Active | General Purpose | - | SP3T, SP4T, SP5T, SP6T | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R599310000IC RF SWITCH SP3T/SP4T/SP5T/SP6T |
2,834 |
|
Datasheet | SPnT | - | Bulk | Active | General Purpose | - | SP3T, SP4T, SP5T, SP6T | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R599309000IC RF SWITCH SP3T/SP4T/SP5T/SP6T |
3,921 |
|
Datasheet | SPnT | - | Bulk | Active | General Purpose | - | SP3T, SP4T, SP5T, SP6T | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
