Rectangular Cable Assemblies
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Connector Type | Number of Positions | Number of Rows | Pitch - Connector | Pitch - Cable | Length | Features | Color | Shielding | Usage | Cable Termination | Contact Finish | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
47626-PIN FEMALE JST SH-STYLE CABLE |
485 |
|
Datasheet | - | Bulk | Active | Socket to Individual Wire Leads | 6 | 1 | 0.039" (1.00mm) | - | 0.375' (114.30mm, 4.50") | - | Multiple, Individual | Unshielded | - | Crimp | Tin | - |
|
17993POS FEMALE JST PH-STYLE CABLE |
1,421 |
|
Datasheet | - | Bulk | Active | Socket to Individual Wire Leads | 3 | 1 | 0.079" (2.00mm) | - | 1.00' (304.80mm) | - | Multiple, Individual | Unshielded | Adapter, Extension | Crimp | Tin | - |
|
|
17983POS FEMALE JST PH-STYLE CABLE |
145 |
|
Datasheet | - | Bulk | Active | Socket to Individual Wire Leads | 3 | 1 | 0.079" (2.00mm) | - | 1.00' (304.80mm) | - | Multiple, Individual | Unshielded | Adapter, Extension | Crimp | Tin | - |
|
47636-PIN FEMALE JST SH-STYLE CABLE |
207 |
|
Datasheet | - | Bulk | Active | Socket to Individual Wire Leads | 6 | 1 | 0.039" (1.00mm) | - | 1.00' (304.80mm) | - | Multiple, Individual | Unshielded | - | Crimp | Tin | - |
|
47656PIN F-F JST SH-STYLE CABLE 10CM |
917 |
|
Datasheet | - | Bulk | Active | Socket to Socket | 6 | 1 | 0.039" (1.00mm) | - | 0.328' (100.00mm, 3.94") | - | - | - | - | Crimp | - | - |
|
47676PIN F-F JST SH-STYLE CABLE 25CM |
476 |
|
Datasheet | - | Bulk | Active | Socket to Socket | 6 | 1 | 0.039" (1.00mm) | - | 0.820' (250.00mm, 9.84") | - | - | - | - | Crimp | - | - |
|
|
47686PIN F-F JST SH-STYLE CABLE 40CM |
177 |
|
Datasheet | - | Bulk | Active | Socket to Socket | 6 | 1 | 0.039" (1.00mm) | - | 1.31' (400.00mm) | - | - | - | - | Crimp | - | - |
|
47646-PIN FEMALE JST SH-STYLE CABLE |
516 |
|
Datasheet | - | Bulk | Active | Socket to Individual Wire Leads | 6 | 1 | 0.039" (1.00mm) | - | 2.50' (762.00mm) | - | Multiple, Individual | Unshielded | - | Crimp | Tin | - |
|
47696PIN F-F JST SH-STYLE CABLE 63CM |
107 |
|
Datasheet | - | Bulk | Active | Socket to Socket | 6 | 1 | 0.039" (1.00mm) | - | 2.07' (630.00mm) | - | - | - | - | Crimp | - | - |
|
|
47666PIN F-F JST SH-STYLE CABLE 16CM |
4,213 |
|
Datasheet | - | Bulk | Active | Socket to Socket | 6 | 1 | 0.039" (1.00mm) | - | 0.525' (160.00mm, 6.30") | - | - | - | - | Crimp | - | - |
