Pressure Sensors, Transducers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Applications | Pressure Type | Operating Pressure | Output Type | Output | Accuracy | Voltage - Supply | Port Size | Port Style | Features | Termination Style | Maximum Pressure | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MPX2053DSENSOR 7.25PSID .04V 4SIP |
1,384 |
|
Datasheet | MPX2053 | 4-SIP Module | Tray | Active | Board Mount | Differential | 7.25PSI (50kPa) | Wheatstone Bridge | 0 mV ~ 40 mV (10V) | - | 10V ~ 16V | - | No Port | Temperature Compensated | PC Pin | 29.01PSI (200kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
MPXH6400AC6UMPXH6400 - PEIZORESISTIVE SENSOR |
1,622 |
|
Datasheet | - | 8-SOIC (0.335", 8.50mm Width), Top Port | Bulk | Obsolete | Industrial Automation | Absolute | 2.9PSI ~ 58.02PSI (20kPa ~ 400kPa) | Analog Voltage | 0.2 V ~ 4.8 V | ±1.5% | 4.64V ~ 5.36V | Male - 0.13" (3.3mm) Tube | Barbless | Temperature Compensated | Gull Wing | 232.06PSI (1600kPa) | -40°C ~ 125°C | - | - | Surface Mount | 8-SSOP |
|
MPXV2202GC6UMPXV2202GC6U - Pressure Sensor, |
3,136 |
|
Datasheet | - | 8-SMD, Gull Wing, Top Port | Bulk | Obsolete | Board Mount | Absolute, Differential, Gauge | 29.01PSI (200kPa) | Wheatstone Bridge | 0 mV ~ 40 mV | - | 10V ~ 16V | Male - 0.19" (4.83mm) Tube, Dual | Barbed | Temperature Compensated | - | 58.02PSI (400kPa) | -40°C ~ 125°C | - | - | Surface Mount | - |
|
MPX4400AMPX4400A - PRES SEN INTEG 20 - 4 |
3,697 |
|
Datasheet | - | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MPX2300DT1SENSOR 5.8PSID .003006V |
2,975 |
|
Datasheet | MPX2300 | 4-SSIP Module | Tape & Reel (TR) | Active | Board Mount | Differential | 5.8PSI (40kPa) | Wheatstone Bridge | 0 mV ~ 3.006 mV (6V) | ±1.5% | 6V ~ 10V | - | No Port | Temperature Compensated | PC Pin | 125PSI (861.84kPa) | 15°C ~ 40°C | - | - | Through Hole | - |
|
MPX10DPSENSOR 1.45PSID 0.19" .035V |
2,633 |
|
Datasheet | MPX10 | 4-SIP Module | Tray | Active | Board Mount | Differential | 1.45PSI (10kPa) | Wheatstone Bridge | 0 mV ~ 35 mV (3V) | ±1% | 3V ~ 6V | Male - 0.19" (4.93mm) Tube, Dual | Barbed | - | PC Pin | 10.88PSI (75kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
MPX10GPSENSOR 1.45PSIG 0.19" .035V |
3,239 |
|
Datasheet | MPX10 | 4-SIP Module | Tray | Active | Board Mount | Vented Gauge | 1.45PSI (10kPa) | Wheatstone Bridge | 0 mV ~ 35 mV (3V) | ±1% | 3V ~ 6V | Male - 0.19" (4.93mm) Tube | Barbed | - | PC Pin | 10.88PSI (75kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
|
MPXH6400AC6USENSOR 58.02PSIA 0.13" 4.8V SSOP |
3,295 |
|
Datasheet | MPXH6400A | 8-SOIC (0.335", 8.50mm Width), Top Port | Tube | Active | Board Mount | Absolute | 2.9PSI ~ 58.02PSI (20kPa ~ 400kPa) | Analog Voltage | 0.2 V ~ 4.8 V | ±1.5% | 4.64V ~ 5.36V | Male - 0.13" (3.3mm) Tube | Barbless | Temperature Compensated | Gull Wing | 232.06PSI (1600kPa) | -40°C ~ 125°C | - | - | Surface Mount | 8-SSOP |
|
MPXHZ6130A6USENSOR 18.85PSIA 4.8V 8SSOP |
1,761 |
|
Datasheet | MPXHZ6130A | 8-SOIC (0.295", 7.50mm Width) | Tube | Active | Board Mount | Absolute | 2.18PSI ~ 18.85PSI (15kPa ~ 130kPa) | Analog Voltage | 0.2 V ~ 4.8 V | ±1.5% | 4.75V ~ 5.25V | - | No Port | Temperature Compensated | Gull Wing | 58.02PSI (400kPa) | -40°C ~ 125°C | - | - | Surface Mount | 8-SSOP |
|
|
MPXHZ6115AC6T1SENSOR 16.68PSIA 0.13" 4.7V SSOP |
1,920 |
|
Datasheet | MPXHZ6115A | 8-SOIC (0.335", 8.50mm Width), Top Port | Tape & Reel (TR) | Active | Board Mount | Absolute | 2.18PSI ~ 16.68PSI (15kPa ~ 115kPa) | Analog Voltage | 0.2 V ~ 4.7 V | ±1.5% | 4.75V ~ 5.25V | Male - 0.13" (3.3mm) Tube | Barbless | Temperature Compensated | Gull Wing | 58.02PSI (400kPa) | -40°C ~ 125°C | - | - | Surface Mount | 8-SSOP |
