DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AM1DS-1205SH30JZ1W DC/DC Converter |
3,009 |
|
Datasheet | * | 7-SIP Module | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Through Hole | - | - | cURus | 62368-1 |
|
|
AM2M-1215DH30JZ2W DC/DC Converter |
2,187 |
|
Datasheet | * | 14-DIP Module | Tube | Obsolete | Isolated Module | 2 | 10.8V | 13.2V | -15 ~ 15V | -15V | - | - | 67mA, 67mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | - | 62368-1 |
|
|
AM2DS-1215DH30JZ2W DC/DC Converter |
4,429 |
|
Datasheet | * | 7-SIP Module | Tube | Obsolete | Isolated Module | 2 | 10.8V | 13.2V | -15 ~ 15V | -15V | - | - | 67mA, 67mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | cURus | 62368-1 |
|
|
AM2DS-2405SH30JZ2W DC/DC Converter |
3,636 |
|
Datasheet | * | 7-SIP Module | Tube | Obsolete | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 400mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Through Hole | - | - | cURus | 62368-1 |
|
|
AM2DS-2405DJZ2W DC/DC Converter |
1,381 |
|
Datasheet | * | 7-SIP Module | Tube | Obsolete | Isolated Module | 2 | 21.6V | 26.4V | -5 ~ 5V | -5V | - | - | 200mA, 200mA | 2 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Through Hole | - | - | cURus | 62368-1 |
|
|
AM2DS-2415DJZ2W DC/DC Converter |
4,422 |
|
Datasheet | * | 7-SIP Module | Tube | Obsolete | Isolated Module | 2 | 21.6V | 26.4V | -15 ~ 15V | -15V | - | - | 67mA, 67mA | 2 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Through Hole | - | - | cURus | 62368-1 |
|
AM2D-1215DH30-RZDC DC CONVERTER +/-15V 2W |
2,549 |
|
Datasheet | AM2D-RZ (2W) | 7-SIP Module | Tube | Active | Isolated Module | 2 | 10.8V | 13.2V | -15 ~ 15V | -15V | - | - | 67mA, 67mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 85°C | 89% | - | - | Through Hole | - | - | CE | - |
|
|
AM1DR-0503SH30JZ1W DC/DC Converter |
3,807 |
|
Datasheet | * | 7-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 4.75V | 5.25V | 3.3V | - | - | - | 250mA | 825 mW | 3 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 67% | - | - | Through Hole | - | - | - | 62368-1 |
|
|
AM1DR-1505SH30JZ1W DC/DC Converter |
1,849 |
|
Datasheet | * | 7-SIP Module, 4 Leads | Tube | Obsolete | Isolated Module | 1 | 14.25V | 15.75V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 73% | - | - | Through Hole | - | - | - | - |
|
AM1DR-0515SH30JZDC DC CONVERTER 15V 1W |
2,727 |
|
Datasheet | AM1DR-NZ (1W) | 7-SIP Module | Tube | Obsolete | Isolated Module | 1 | 4.75V | 5.25V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 85°C | 73% | - | - | Through Hole | - | - | cULus, cURus | - |
