DC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Number of Outputs | Voltage - Input (Min) | Voltage - Input (Max) | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Current - Output (Max) | Power (Watts) | Voltage - Isolation | Applications | Features | Operating Temperature | Efficiency | Grade | Qualification | Mounting Type | Supplier Device Package | Control Features | Approval Agency | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HRC0524S4K0NHV DC-DC 5W 4000V |
2,527 |
|
Datasheet | HRC05 (5W) | 10-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | 0 ~ -4000V | - | - | - | 1.25mA | 5 W | - | ITE (Commercial), Laboratory | Adjustable Output | -40°C ~ 70°C | - | - | - | Through Hole | - | - | UL | 61010-1; 62368-1 |
|
C50NDC DC CONVERTER -5000V 1W |
1,277 |
|
Datasheet | XP EMCO - C (1W) | 5-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 11.5V | 16V | -5000V | - | - | - | 200µA | 1 W | - | ITE (Commercial) | SCP | -10°C ~ 60°C | - | - | - | Through Hole | - | - | - | 62368-1 |
|
C60NDC DC CONVERTER -6000V 1W |
2,239 |
|
Datasheet | XP EMCO - C (1W) | 5-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 11.5V | 16V | -6000V | - | - | - | 166µA | 1 W | - | ITE (Commercial) | SCP | -10°C ~ 60°C | - | - | - | Through Hole | - | - | - | 62368-1 |
|
|
C80NDC DC CONVERTER -8000V 1W |
3,507 |
|
Datasheet | XP EMCO - C (1W) | 5-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 11.5V | 16V | -8000V | - | - | - | 125µA | 1 W | - | ITE (Commercial) | SCP | -10°C ~ 60°C | - | - | - | Through Hole | - | - | - | 62368-1 |
|
C80DC DC CONVERTER 8000V 1W |
4,924 |
|
Datasheet | XP EMCO - C (1W) | 5-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 11.5V | 16V | 8000V | - | - | - | 125µA | 1 W | - | ITE (Commercial) | SCP | -10°C ~ 60°C | - | - | - | Through Hole | - | - | - | 62368-1 |
|
HRL3024S1K0NDC DC CONVERTER -1000V 30W |
2,826 |
|
Datasheet | HRL30 (30W) | 14-DIP Module | Tray | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | -1000V | - | - | - | 30mA | 30 W | - | ITE (Commercial) | Adjustable Output, Baseplate | -40°C ~ 70°C | 85% | - | - | Through Hole | - | - | CE, UKCA, UL | 62368-1 |
|
HRL3024S1K5PDC DC CONVERTER 1500V 30W |
4,589 |
|
Datasheet | HRL30 (30W) | 14-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | 1500V | - | - | - | 20mA | 30 W | - | ITE (Commercial) | Adjustable Output, Baseplate | -40°C ~ 70°C | 85% | - | - | Through Hole | - | - | CE, UKCA, UL | 60950-1; 62368-1 |
|
HRL3024S1K5NDC DC CONVERTER -1500V 30W |
3,256 |
|
Datasheet | HRL30 (30W) | 14-DIP Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | -1500V | - | - | - | 20mA | 30 W | - | ITE (Commercial) | Adjustable Output, Baseplate | -40°C ~ 70°C | 85% | - | - | Through Hole | - | - | CE, UKCA, UL | 60950-1; 62368-1 |
|
|
HRL3024S6K0NDC DC CONVERTER -6000V 30W |
1,372 |
|
Datasheet | HRL30 (30W) | 14-DIP Module | Tray | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | -6000V | - | - | - | 5mA | 30 W | - | ITE (Commercial) | Adjustable Output, Baseplate | -40°C ~ 70°C | 85% | - | - | Through Hole | - | - | CE, UKCA, UL | 62368-1 |
|
ITB0505SDC DC CONVERTER 5V 1W |
4,723 |
|
Datasheet | ITB (1W) | 7-SIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C | 80% | - | - | Through Hole | - | - | - | - |
