Power Relays, Over 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
40.61.9.024.0000RELAY GEN PURPOSE SPDT 16A 24V |
3,824 |
|
Datasheet | 40 | Bulk | Obsolete | Socketable | 24VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 27 mA | Non Latching | - | Plug In | Sealed - Flux Protection | - | 17.5 VDC | 4.8 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
40.61.7.024.2020RELAY GEN PURPOSE SPDT 16A 24V |
3,643 |
|
Datasheet | 40 | Bulk | Obsolete | Through Hole | 24VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 21 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 17.5 VDC | 2.4 VDC | 10 ms | 3 ms | -40°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
|
40.61.9.024.0300RELAY GEN PURPOSE SPST 16A 24V |
1,740 |
|
Datasheet | 40 | Bulk | Obsolete | Socketable | 24VDC | SPST-NO (1 Form A) | 16 A | 400VAC - Max | 6400VA | 27 mA | Non Latching | - | Plug In | Sealed - Flux Protection | - | 17.5 VDC | 4.8 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
|
40.61.7.012.0000RELAY GEN PURPOSE SPDT 16A 12V |
4,773 |
|
Datasheet | 40 | Bulk | Obsolete | Socketable | 12VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 42 mA | Non Latching | - | Plug In | Sealed - Flux Protection | - | 8.8 VDC | 2.4 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
|
40.61.7.012.1020RELAY GEN PURPOSE SPDT 16A 12V |
1,646 |
|
Datasheet | 40 | Box | Active | Socketable | 12VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 42 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 8.8 VDC | 1.2 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
|
40.51.9.024.0300PCB/PLUG-IN RELAY, SPST-NO 10A, |
2,143 |
|
Datasheet | 40 | Bulk | Active | Socketable | 24VDC | SPST-NO (1 Form A) | 12 A | 400VAC - Max | 4800VA | 27 mA | Non Latching | - | Plug In | Sealed - Flux Protection | - | 17.5 VDC | 4.8 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
41.52.9.024.0011RELAY GEN PURPOSE DPDT 8A 24V |
4,196 |
|
Datasheet | 41 | Bulk | Active | Through Hole | 24VDC | DPDT (2 Form C) | 8 A | 400VAC - Max | 3200VA | 16.7 mA | Non Latching | - | PC Pin | - | - | 16.8 VDC | 3.6 VDC | 8 ms | 6 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
40.51.9.012.2300RELAY GEN PURPOSE SPST 10A 12V |
4,987 |
|
Datasheet | 40 | Bulk | Obsolete | Socketable | 12VDC | SPST-NO (1 Form A) | 10 A | 400VAC - Max | 4000VA | 55 mA | Non Latching | - | Plug In | Sealed - Flux Protection | - | 8.8 VDC | 2.4 VDC | 7 ms | 3 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
41.61.9.024.4010RELAY GEN PURPOSE SPDT 16A 24V |
2,407 |
|
Datasheet | 41 | Bulk | Active | Through Hole | 24VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 16.7 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 16.8 VDC | 3.6 VDC | 8 ms | 6 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
|
41.61.9.024.4310RELAY GEN PURPOSE SPST 16A 24V |
1,518 |
|
Datasheet | 41 | Bulk | Active | Through Hole | 24VDC | SPDT (1 Form C) | 16 A | 400VAC - Max | 6400VA | 16.7 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 16.8 VDC | 3.6 VDC | 8 ms | 6 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
