Power Relays, Over 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2765150000DRL273012L |
3,133 |
|
Datasheet | DRL | Box | Active | Socketable | 12VDC | DPDT (2 Form C) | 10 A | 250VAC, 24VDC - Max | 2500VA, 300W | 75 mA | Non Latching | Lighted Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | - | - | 20 ms | 20 ms | -25°C ~ 55°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
|
2765380000DRL173615L |
4,302 |
|
Datasheet | DRL | Box | Active | Socketable | 115VAC | SPDT (1 Form C) | 16 A | 250VAC, 24VDC - Max | 4000VA, 480W | 12.9 mA | Non Latching | Lighted Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | - | - | 20 ms | 20 ms | -25°C ~ 55°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
8870150000RELAY GEN PURPOSE SPDT 16A 230V |
2,525 |
|
Datasheet | RCI | Bulk | Active | Through Hole | 230VAC | SPDT (1 Form C) | 16 A | 250VAC - Max | 4000VA | 3.2 mA | Non Latching | Lighted Indicator | PC Pin | - | - | 172.5 VAC | 34.5 VAC | 8 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
8870010000RELAY GEN PURPOSE SPDT 16A 230V |
2,717 |
|
Datasheet | RCI | Bulk | Active | Through Hole | 230VAC | SPDT (1 Form C) | 16 A | 250VAC - Max | 4000VA | 3.2 mA | Non Latching | Test Button | PC Pin | - | - | 172.5 VAC | 34.5 VAC | 8 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
8870340000RELAY GEN PURPOSE DPDT 8A 110V |
1,010 |
|
Datasheet | RCI | Bulk | Active | Through Hole | 110VDC | DPDT (2 Form C) | 8 A | 250VAC - Max | 2000VA | 4.1 mA | Non Latching | Diode, Lighted Indicator, Test Button | PC Pin | - | - | 77 VDC | 11 VDC | 10 ms | 4 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
8689850000RELAY GEN PURPOSE DPDT 12A 12V |
2,646 |
|
Datasheet | RCM | Bulk | Active | Socketable | 12VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 62.5 mA | Non Latching | Lighted Indicator, Test Button | Plug In, Quick Connect - 0.110" (2.8mm) | - | - | 9 VDC | 1.2 VDC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
2765200000RELAY GEN PURPOSE 3PDT 10A 220V |
3,838 |
|
Datasheet | DRR | Bulk | Active | Socketable | 220VDC | 3PDT (3 Form C) | 10 A | 250VAC, 24VDC - Max | 2500VA, 240W | 7.6 mA | Non Latching | Lighted Indicator, Mechanical Indicator | Plug In, 11 Pin (Octal) | - | - | - | - | 30 ms | 20 ms | -25°C ~ 55°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
|
2765400000RELAY GEN PURPOSE DPDT 10A 24V |
3,475 |
|
Datasheet | DRL | Bulk | Active | Socketable | 24VAC | DPDT (2 Form C) | 10 A | 250VAC, 24VDC - Max | 2500VA, 300W | 54 mA | Non Latching | Lighted Indicator, Mechanical Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | - | - | 20 ms | 20 ms | -25°C ~ 55°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
|
2765170000RELAY GEN PURPOSE DPDT 10A 48V |
4,864 |
|
Datasheet | DRL | Bulk | Active | Socketable | 48VDC | DPDT (2 Form C) | 10 A | 250VAC, 24VDC - Max | 2500VA, 300W | 18.5 mA | Non Latching | Lighted Indicator, Mechanical Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | - | - | 20 ms | 20 ms | -25°C ~ 55°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
8870080000RELAY GEN PURPOSE DPDT 8A 230V |
2,546 |
|
Datasheet | RCI | Bulk | Active | Through Hole | 230VAC | DPDT (2 Form C) | 8 A | 250VAC - Max | 2000VA | 3.2 mA | Non Latching | Test Button | PC Pin | - | - | 172.5 VAC | 34.5 VAC | 10 ms | 4 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
