Power Distribution Switches, Load Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Switch Type | Number of Outputs | Ratio - Input:Output | Output Configuration | Output Type | Interface | Voltage - Load | Voltage - Supply (Vcc/Vdd) | Current - Output (Max) | Rds On (Typ) | Input Type | Features | Fault Protection | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CA3272AMQUAD-GATED INVERTING POWER DRIVE |
3,794 |
|
Datasheet | 28-SOIC (0.295", 7.50mm Width) | - | Bulk | Active | Relay, Solenoid Driver | 4 | 1:1 | Low Side | Bipolar | On/Off | 15V | 7V | 600mA | - | Non-Inverting | Load Discharge, Status Flag | Current Limiting (Fixed), Over Temperature, Over Voltage | -40°C ~ 125°C (TA) | - | - | Surface Mount | 28-SOIC |
|
CA3292AM96QUAD-GATED INVERTING POWER DRIVE |
558 |
|
Datasheet | 28-SOIC (0.295", 7.50mm Width) | - | Bulk | Active | Relay, Solenoid Driver | 4 | 1:1 | Low Side | Bipolar | On/Off | 15V | 7V | 600mA | - | Non-Inverting | Load Discharge, Status Flag | Current Limiting (Fixed), Over Temperature, Over Voltage | -40°C ~ 125°C (TA) | - | - | Surface Mount | 28-SOIC |
|
CA3292AMQUAD-GATED INVERTING POWER DRIVE |
271 |
|
Datasheet | 28-SOIC (0.295", 7.50mm Width) | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | - |
|
CA3272QQUAD-GATED INVERTING POWER DRIVE |
4,237 |
|
Datasheet | 28-LCC (J-Lead) | - | Bulk | Active | Relay, Solenoid Driver | 4 | 1:1 | Low Side | Bipolar | On/Off | 60V | 7V | 600mA | - | Inverting | Load Discharge, Status Flag | Current Limiting (Fixed), Over Temperature | -40°C ~ 125°C (TA) | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
SP710ASBUFFER/INVERTER BASED PERIPHERAL |
5,559 |
|
Datasheet | TO-220-3 | - | Bulk | Active | General Purpose | 1 | 1:1 | - | N-Channel | - | 4V ~ 16V | Not Required | 800mA | - | Non-Inverting | - | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 125°C (TA) | - | - | Through Hole | TO-220AB |
|
HIP0050IP0.3A/50V OCTAL LOW SIDE POWER DR |
2,125 |
|
Datasheet | 20-DIP (0.300", 7.62mm) | - | Bulk | Active | General Purpose | 8 | 1:1 | Low Side | N-Channel | On/Off | 5V | Not Required | 2A | 2Ohm | Non-Inverting | Status Flag | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 85°C (TA) | - | - | Through Hole | 20-PDIP |
|
HIP0050IB-HC0.3A/50V OCTAL LOW SIDE POWER DR |
2,016 |
|
Datasheet | 24-SOIC (0.295", 7.50mm Width) | - | Bulk | Active | General Purpose | 8 | 1:1 | Low Side | N-Channel | SPI | 5V | Not Required | 2A | 2Ohm | Non-Inverting | Status Flag | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 85°C (TA) | - | - | Surface Mount | 24-SOIC |
|
|
CA3272QXINVERTING POWER DRIVER |
383 |
|
Datasheet | 28-LCC (J-Lead) | - | Bulk | Active | Relay, Solenoid Driver | 4 | 1:1 | Low Side | Bipolar | On/Off | 60V | 7V | 600mA | - | Inverting | Load Discharge, Status Flag | Current Limiting (Fixed), Over Temperature | -40°C ~ 125°C (TA) | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
|
HIP1090ASPROTECTED HIGH SIDE POWER SWITCH |
6,191 |
|
Datasheet | TO-220-3 | - | Bulk | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 4V ~ 16V | Not Required | 1A | - | Non-Inverting | - | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 125°C (TA) | - | - | Through Hole | TO-220AB |
|
|
HIP0050IB960.3A/50V OCTAL LOW SIDE POWER DR |
31,000 |
|
Datasheet | 24-SOIC (0.295", 7.50mm Width) | - | Bulk | Active | Latched Driver | 8 | 1:1 | Low Side | N-Channel | On/Off, Parallel, SPI, Strobe | 5V | Not Required | 2A | 2Ohm | Inverting | Latch Function, Status Flag | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 85°C (TA) | - | - | Surface Mount | 24-SOIC |
