Panel Indicators, Pilot Lights
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Lamp Color | Lens Color | Lens Transparency | Ratings | Voltage | Current | Panel Cutout Shape | Panel Cutout Dimensions | Lens Size | Lens Style | Millicandela Rating | Wavelength - Peak | Viewing Angle | Termination Style | Ingress Protection | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
6803132231F10MM HR/R PMI-12VDC |
4,168 |
|
Datasheet | 680 | Bag | Active | LED | Red | - | - | DC | 12V | 30mA | Round | 0.37" (9.40mm) | - | - | 335mcd | - | - | Solder Lug | - | - |
|
QS81XXHO110INDICATOR 8MM FIXED HI ORA 110V |
1,619 |
|
Datasheet | QS | Bulk | Active | LED | Orange | Orange | Diffused | AC | 110V | 6mA | Round | 0.315" (8.00mm) | 10.00mm Dia | Round with Flat Top | 4100mcd | - | 45° | Solder Lug | - | - |
|
QS83XXHO110INDICATOR 8MM FIXED HI ORA 110V |
1,407 |
|
Datasheet | QS | Bulk | Active | LED | Orange | Orange | Diffused | AC | 110V | 6mA | Round | 0.315" (8.00mm) | 10.00mm Dia | Round with Flat Top | 4100mcd | - | 45° | Wire Leads - 7.87" (200.00mm) | - | - |
|
QS83XXHO220INDICATOR 8MM FIXED HI ORA 220V |
1,178 |
|
Datasheet | QS | Bulk | Active | LED | Orange | Orange | Diffused | AC | 220V | 3mA | Round | 0.315" (8.00mm) | 10.00mm Dia | Round with Flat Top | 4100mcd | - | 45° | Wire Leads - 7.87" (200.00mm) | - | - |
|
CNX722C40005W22MM YELLOW 5V WIRES |
4,670 |
|
Datasheet | CNX 722 TuffLED™ | Bulk | Obsolete | LED | Yellow | Yellow | Diffused | DC | 5V | 20mA | Round | 0.88" (22.35mm) | 25.60mm Dia | Round with Domed Top | 140mcd | - | - | Wire Leads - 6" (152.40mm) | IP67, NEMA 6P | - |
|
CD-0-8711-9933-IPMI DIA .236" (6MM) BLUE 26V |
2,816 |
|
Datasheet | CD | Bag | Active | LED | - | Blue | - | DC | 28V | 20mA | Round | 0.236" (6.00mm) | - | Round with Domed Top | 2300mcd | 470nm | 25° | PC Pin | IP67 | - |
|
C430ALBA2-G74INDICATOR 110V AMBER |
3,072 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | Rectangle | 0.48" x 1.07" (12.25mm x 27.25mm) | - | Rectangle with Flat Top | - | - | - | - | - | - |
|
|
91-BCR120-CROPMI RED 626NM 120V RD CLR CYL |
1,910 |
|
Datasheet | 90 | Bulk | Active | LED | Red | Red | Clear | AC | 120V | 3.5mA | Round | 0.29" (7.37mm) | 7.10mm Dia | Round with Flat Top | 120mcd | 635nm | 35° | Wire Wrap, 0.201" (5.1mm) | - | - |
|
|
HA2P-0OPERATOR |
3,337 |
|
Datasheet | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
HA3P-0OPERATOR |
1,956 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
UP7-78-W7MM |
2,769 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
UP7-79-W7MM |
2,976 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
UP06-69-A6MM |
1,575 |
|
- |
UP06 | Bulk | Obsolete | LED | Amber | - | - | Vf (Typ), If (Max) | 2V | 20mA | Round | 0.24" (6.10mm) | - | Round with Domed Top | - | - | - | Wire Wrap | IP40 | - |
|
|
1.69.507.125/1601INCAND PANEL INDICATOR BLUE 28V |
1,947 |
|
Datasheet | - | Bulk | Obsolete | Incandescent | Blue | Blue | Clear | - | 28V | - | Round | 0.42" (10.60mm) | - | - | - | - | - | Quick Connect - 0.110" (2.8mm) | - | - |
|
|
L16PLT10FREDREDNEON PANEL INDICATOR RED 110V |
4,008 |
|
Datasheet | L16 | Bulk | Active | Neon | Red | - | - | AC | 110V | - | Round | 0.63" (16.00mm) | 24.00mm x 18.00mm | Rectangle with Flat Top | - | - | - | - | - | - |
|
UB01KW035CINDICATOR SQ BLK HSNG RED LED |
1,203 |
|
Datasheet | UB | Box | Active | LED | Red | - | - | Vf (Typ), If (Max) | 1.85V | 30mA | Square | 0.60" x 0.60" (15.24mm x 15.24mm) | 12.00mm | Square with Flat Top | - | - | - | - | - | - |
|
5580803802FLED PMI B Y/G ASSY W CNECT |
4,992 |
|
- |
558 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
5590201819FLED SNAP-IN PANEL IND |
4,349 |
|
- |
559 | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
M22R-ER-12AINDICATOR,RED,12V |
2,240 |
|
Datasheet | M22R | Bulk | Obsolete | LED | Red | - | - | AC | 12V | 20mA | Round | 0.88" (22.35mm) | 29.80mm Dia | Round with Flat Top | - | - | - | - | IP65 | - |
|
|
XA2EVF8LCDIA 22, PILOT LIGHT, 110V AC/DC, |
1,770 |
|
Datasheet | Easy Harmony XA2 | Box | Active | LED | Yellow | Yellow | Diffused | AC/DC | 110V | 20mA | Round | 0.89" (22.50mm) | 29.00mm Dia | Round with Flat Top | - | - | - | Screw Terminal | IP65 | - |
