Panel Indicators, Pilot Lights
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Lamp Color | Lens Color | Lens Transparency | Ratings | Voltage | Current | Panel Cutout Shape | Panel Cutout Dimensions | Lens Size | Lens Style | Millicandela Rating | Wavelength - Peak | Viewing Angle | Termination Style | Ingress Protection | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Q6F1CXXY12INDICATOR 12V 6MM FLUSH YLW |
3,106 |
|
Datasheet | Q6 | Bag | Active | LED | Yellow | Yellow | Diffused | DC | 12V | 20mA | Round | 0.24" (6.10mm) | 3mm, T-1 | Round with Flat Top | 8mcd | - | 100° | Solder Lug | - | - |
|
|
Q6F1CXXG12INDICATOR 12V 6MM FLUSH GREEN |
4,097 |
|
Datasheet | Q6 | Bag | Active | LED | Green | Green | Diffused | DC | 12V | 20mA | Round | 0.24" (6.10mm) | 3mm, T-1 | Round with Flat Top | 8mcd | - | 100° | Solder Lug | - | - |
|
|
Q8R1CXXG24INDICATOR 24V 8MM RECESSED GRN |
2,168 |
|
Datasheet | Q8 | Bag | Obsolete | LED | Green | Green | Diffused | DC | 24V | 20mA | Round | 0.31" (7.87mm) | 5mm, T-1 3/4 | Round with Domed Top | 60mcd | - | 100° | Solder Lug | - | - |
|
|
Q6F3BXXSG12LED PANEL INDICATOR GRN 12V |
2,993 |
|
Datasheet | Q6 | Bag | Active | LED | Green | Colorless | Clear | DC | 12V | 20mA | Round | 0.24" (6.10mm) | 3mm, T-1 | Round with Flat Top | 350mcd | - | 100° | Wire Leads - 7.87" (200.00mm) | - | - |
|
Q8P3BXXHB110ELED PMI PROMINENT 110VAC BLUE |
1,421 |
|
Datasheet | Q8 | Bag | Active | LED | Blue | Blue | Diffused | AC | 110V | 6mA | Round | 0.31" (7.87mm) | 5mm, T-1 3/4 | Round with Domed Top | 90mcd | - | 100° | Wire Leads - 7.87" (200.00mm) | IP67 | - |
|
QRM85BXXW24ELED PMI REAR MOUNT WHITE |
4,020 |
|
Datasheet | QRM | Bag | Active | LED | White | White | Diffused | DC | 24V | 20mA | Round | 0.32" (8.13mm) | 5mm, T-1 3/4 | Round with Flat Top | 25mcd | - | 60° | Wire Leads - 7.87" (200.00mm) | IP67 | - |
|
Q6P7CXXB02ELED PM INDICATOR PROMINENT BLUE |
2,837 |
|
Datasheet | Q6 | Bag | Active | LED | Blue | Blue | Diffused | Vf (Typ), If (Max) | 3.8V | 20mA | Round | 0.24" (6.10mm) | 3mm, T-1 | Round with Domed Top | 1200mcd | - | 100° | Wire Leads - 7.87" (200.00mm) | IP67 | - |
|
Q6P7CXXW02ELED PM INDICATOR PROMINENT WHT |
1,125 |
|
Datasheet | Q6 | Bag | Active | LED | White | White | Diffused | Vf (Typ), If (Max) | 3.8V | 20mA | Round | 0.24" (6.10mm) | 3mm, T-1 | Round with Domed Top | 1200mcd | - | 100° | Wire Leads - 7.87" (200.00mm) | IP67 | - |
|
Q14F3CXXHW110ELED PMI FLUSH 110VAC WHITE |
4,115 |
|
Datasheet | Q14 | Bag | Active | LED | White | White | Diffused | AC | 110V | 6mA | Round | 0.55" (13.97mm) | 10.00mm Dia | Round with Flat Top | - | - | 100° | Wire Leads - 7.87" (200.00mm) | IP67 | - |
|
QS83XXHW110INDICATOR 8MM FIXED HI WHT 110V |
4,390 |
|
Datasheet | QS | Bulk | Obsolete | LED | White | White | Diffused | AC | 110V | 6mA | Round | 0.315" (8.00mm) | 10.00mm Dia | Round with Flat Top | 2500mcd | - | 45° | Wire Leads - 7.87" (200.00mm) | - | - |
