Multiple Conductor Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Wire Gauge | Conductor Strand | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Shield Type | Length | Jacket Color | Ratings | Features | Voltage | Operating Temperature | Usage | Jacket (Insulation) Thickness | Conductor Insulation | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
35103 BK199CABLE 3COND 22AWG BLK SHLD 1000' |
2,717 |
|
Datasheet | Xtra-Guard® 3 | Spool | Active | Multi-Conductor | 3 | 22 AWG | 7/30 | Copper, Tinned | Polyethylene (PE) | 0.203" (5.16mm) | Foil, Braid | 1000.0' (304.8m) | Black | - | Drain Wire, Rip Cord | 300 V | -30°C ~ 80°C | - | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
35493 BK199MULTI-PAIR 6COND 24AWG BLK 1000' |
4,322 |
|
Datasheet | Xtra-Guard® 3 | Spool | Active | Multi-Pair | 6 (3 Pair Twisted) | 24 AWG | 7/32 | Copper, Tinned | Polyethylene (PE) | 0.227" (5.77mm) | Foil | 1000.0' (304.8m) | Black | - | Drain Wire, Rip Cord | 300 V | -30°C ~ 80°C | - | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
78372 SL199MULT-PAIR 4COND 24AWG SLATE SHLD |
4,460 |
|
Datasheet | EcoCable® Mini | Bulk | Active | Multi-Pair | 4 (2 Pair Twisted) | 24 AWG | 19/36 | Copper, Tinned | Polyphenylene Ether, Modified (mPPE) | 0.193" (4.90mm) | Foil, Braid | - | Slate | ISO 10993, UL Style 21460 | Biological Compatibility, Drain Wire, Rip Cord | 300 V | -40°C ~ 80°C | - | 0.0150" (0.381mm) | Polyphenylene Ether, Modified (mPPE) | - |
|
|
77252 SL199CABLE 2COND 28AWG SHLD 100=100' |
4,336 |
|
Datasheet | EcoCable® | Spool | Active | Multi-Conductor | 2 | 28 AWG | 7/36 | Copper, Tinned | Polyphenylene Ether, Modified (mPPE) | 0.166" (4.22mm) | Foil, Braid | - | Slate | ISO 10993, UL Style 21915 | Biological Compatibility, Drain Wire, Rip Cord | 600 V | -50°C ~ 105°C | - | 0.0320" (0.813mm) | Polyphenylene Ether, Modified (mPPE) | - |
|
|
80134 SL199CABLE 4COND 18AWG SLATE SHLD |
3,302 |
|
Datasheet | EcoFlex® PUR | Bulk | Active | Multi-Conductor | 4 | 18 AWG | 41/34 | Copper, Tinned | Polyurethane (PU) | 0.259" (6.58mm) | Braid | - | Slate | - | - | 600 V | -50°C ~ 90°C | - | 0.0320" (0.813mm) | Polyphenylene Ether, Modified (mPPE) | - |
|
|
80024 SL199CABLE 7COND 20AWG SLATE |
2,500 |
|
Datasheet | EcoFlex® PUR | Bulk | Active | Multi-Conductor | 7 | 20 AWG | 26/34 | Copper, Tinned | Polyurethane (PU) | 0.234" (5.94mm) | - | - | Slate | - | - | 600 V | -50°C ~ 90°C | - | 0.0320" (0.813mm) | Polyphenylene Ether, Modified (mPPE) | - |
|
|
M9708160 BK001MULTI-PAIR 32COND 18AWG |
3,475 |
|
Datasheet | - | Spool | Active | Multi-Pair | 32 (16 Pair Twisted) | 18 AWG | 7/0.0152" | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.764" (19.41mm) | Foil | 1000.0' (304.8m) | Black | - | - | 300 V | -20°C ~ 105°C | - | 0.0630" (1.600mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
652425 SL001CABLE 25COND 24AWG SLATE |
3,592 |
|
Datasheet | Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 25 | 24 AWG | 7/32 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.525" (13.34mm) | - | 1000.0' (304.8m) | Slate | UL Style 2587 | Oil Resistant | 600 V | - | - | 0.0500" (1.270mm) | Poly-Vinyl Chloride (PVC) | - |
|
80122 SL005CABLE 5COND 20AWG SLATE SHLD |
2,535 |
|
Datasheet | EcoFlex® PUR | Spool | Active | Multi-Conductor | 5 | 20 AWG | 26/34 | Copper, Tinned | Polyurethane (PU) | 0.245" (6.22mm) | Braid | 100.0' (30.5m) | Slate | - | - | 600 V | -50°C ~ 90°C | - | 0.0319" (0.810mm) | Polyphenylene Ether (PPE) | - |
|
|
5269C SL001MULTI-PAIR 18COND 24AWG |
4,900 |
|
Datasheet | Xtra-Guard® 1 | Spool | Active | Multi-Pair | 18 (9 Pair Twisted) | 24 AWG | 7/32 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.332" (8.43mm) | - | 1000.0' (304.8m) | Slate | ISO 10993 | Biological Compatibility, Rip Cord | 300 V | -35°C ~ 105°C | Communication, Control | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
