Flat Ribbon Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Pitch | Length | Wire Gauge | Conductor Strand | Shielding | Jacket Color | Ribbon Thickness | Ribbon Width | Jacket (Insulation) Material | Voltage | Operating Temperature | Ratings | Features | Ratings | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
C3319/14 100CBL RIBN 14COND 0.05 BLACK 50' |
3,694 |
|
Datasheet | 3319 | Bulk | Active | Flat Cable | 14 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 19 Strands / 40 AWG | Unshielded | Black | 0.035" (0.89mm) | 0.700" (17.78mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Zippable |
|
3517/34 100SFCBL RIBN 34COND 0.05 GRAY 25' |
3,208 |
|
Datasheet | 3517 | Bulk | Active | Flat Cable, Flat Jacket | 34 | 0.050" (1.27mm) | 25.0' (7.62m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Gray | 0.110" (2.79mm) | 1.830" (46.48mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 80°C | UL Style 2912 | Splice Free |
|
1785/40 100SFCBL RIBN 40COND TWIST PAIR 25' |
3,959 |
|
Datasheet | 1785 | Bulk | Active | Flat Twisted Pair, Flat Jacket | 40 (20 Pair Twisted) | 0.050" (1.27mm) | 25.0' (7.62m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Black | 0.120" (3.05mm) | 2.130" (54.10mm) | Poly-Vinyl Chloride (PVC) | 150 V | - | - | -20°C ~ 80°C | UL Style 2912 | Splice Free |
|
3517/16 100SFCBL RIBN 16COND 0.05 GRAY 50' |
1,170 |
|
Datasheet | 3517 | Bulk | Active | Flat Cable, Flat Jacket | 16 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Gray | 0.110" (2.79mm) | 0.930" (23.62mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 80°C | UL Style 2912 | Splice Free |
|
2010/50 100SFCBL RIBN 50COND 0.05 WHITE 100' |
4,973 |
|
Datasheet | 2010 | Spool | Obsolete | Flat Cable | 50 | 0.050" (1.27mm) | 100.0' (30.48m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | White | 0.035" (0.89mm) | 2.500" (63.50mm) | Polyolefin (PO) | 30 V | - | - | -20°C ~ 105°C | UL Style 20930 | Splice Free, Zippable |
|
3517/15 100CBL RIBN 15COND 0.05 GRAY 50' |
4,356 |
|
Datasheet | 3517 | Bulk | Active | Flat Cable, Flat Jacket | 15 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Gray | 0.110" (2.79mm) | 0.880" (22.35mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 80°C | UL Style 2912 | - |
.jpg)
|
3302/64 100CBL RIBN 64COND 0.05 MULTI 50' |
3,233 |
|
Datasheet | 3302 | Bulk | Active | Flat Cable | 64 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Unshielded | Multiple | 0.042" (1.07mm) | 3.200" (81.28mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 20462 | Zippable |
|
1785/16 100SFCBL RIBN 16COND TWIST PAIR 50' |
1,235 |
|
Datasheet | 1785 | Bulk | Active | Flat Twisted Pair, Flat Jacket | 16 (8 Pair Twisted) | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 7 Strands / 36 AWG | Shielded | Black | 0.120" (3.05mm) | 0.930" (23.62mm) | Poly-Vinyl Chloride (PVC) | 150 V | - | - | -20°C ~ 80°C | UL Style 2912 | Splice Free |
|
HF539/34CBL RIBN 34COND 0.05 GRAY 50' |
4,416 |
|
Datasheet | HF539 | Box | Discontinued at Digi-Key | Flat Cable | 34 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 19 Strands / 40 AWG | Unshielded | Gray | 0.035" (0.89mm) | 1.700" (43.18mm) | Polyolefin (PO) | 300 V | - | - | -40°C ~ 105°C | UL Style 21682 | Zippable |
|
3319/10SF 300CBL RIBN 10COND 0.05 BLACK 50' |
1,999 |
|
Datasheet | 3319 | Bulk | Active | Flat Cable | 10 | 0.050" (1.27mm) | 50.0' (15.24m) | 28 AWG | 19 Strands / 40 AWG | Unshielded | Black | 0.035" (0.89mm) | 0.500" (12.70mm) | Poly-Vinyl Chloride (PVC) | 300 V | - | - | -20°C ~ 105°C | UL Style 2651 | Zippable |
