DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CBM-7530CF-260-540DC BLOWER, 49.2 X 49.8 X 20 MM, |
1,671 |
|
Datasheet | CBM-75CF | Box | Active | 24VDC | Square/Rounded - 75.7mm L x 75.7mm H | 24.50mm | 17.9 CFM (0.501m³/min) | 1.320 in H2O (328.8 Pa) | omniCOOL™ Magnetic Sleeve | Blower | Auto Restart | 54.0dB(A) | 16.56 W | 6000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-979433B-235-540-22FAN BLOWER 97.68X32.7MM 24VDC |
1,605 |
|
Datasheet | CBM-97B-2 | Box | Active | 24VDC | Rectangular/Rounded - 97.68mm L x 94.18mm H | 32.70mm | 23.9 CFM (0.669m³/min) | 0.900 in H2O (224.2 Pa) | Ball | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 54.1dB(A) | 12.24 W | 3500 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-6025BF-190-479-20FAN AXIAL 60X25.4MM 12VDC WIRE |
2,014 |
|
Datasheet | CFM-60BF | Box | Active | 12VDC | Square - 60mm L x 60mm H | 25.40mm | 43.1 CFM (1.21m³/min) | 0.720 in H2O (179.3 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 47.9dB(A) | 8.28 W | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-A232B-120-457-20FAN BLOWER 119.3X32MM 12VDC WIRE |
2,225 |
|
Datasheet | CBM-120B-2 | Box | Active | 12VDC | Square/Rounded - 119.3mm L x 119mm H | 32.00mm | 18.5 CFM (0.518m³/min) | 0.600 in H2O (149.5 Pa) | Ball | Blower | Auto Restart, Speed Sensor (Tach) | 45.8dB(A) | 4.56 W | 2000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-A232B-220-457-20FAN BLOWER 119.3X32MM 24VDC WIRE |
1,367 |
|
Datasheet | CBM-120B-2 | Box | Active | 24VDC | Square/Rounded - 119.3mm L x 119mm H | 32.00mm | 18.5 CFM (0.518m³/min) | 0.600 in H2O (149.5 Pa) | Ball | Blower | Auto Restart, Speed Sensor (Tach) | 45.8dB(A) | 4.32 W | 2000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-A232B-225-481-20FAN BLOWER 119.3X32MM 24VDC WIRE |
3,161 |
|
Datasheet | CBM-120B-2 | Box | Active | 24VDC | Square/Rounded - 119.3mm L x 119mm H | 32.00mm | 23.1 CFM (0.647m³/min) | 0.940 in H2O (234.1 Pa) | Ball | Blower | Auto Restart, Speed Sensor (Tach) | 48.2dB(A) | 8.64 W | 2500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-8038B-250-498-20FAN AXIAL 80X37.6MM 24VDC WIRE |
2,532 |
|
Datasheet | CFM-80B | Box | Active | 24VDC | Square - 80mm L x 80mm H | 37.60mm | 61.8 CFM (1.73m³/min) | 0.580 in H2O (144.5 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 49.8dB(A) | 10.8 W | 5000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-8038S-250-498-20FAN AXIAL 80X37.6MM 24VDC WIRE |
1,676 |
|
Datasheet | CFM-80S | Box | Active | 24VDC | Square - 80mm L x 80mm H | 37.60mm | 61.8 CFM (1.73m³/min) | 0.580 in H2O (144.5 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 49.8dB(A) | 10.8 W | 5000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-6025BG68-135-253DC AXIAL FAN, 60 MM SQUARE, 25 M |
1,641 |
|
Datasheet | CFM-60BG68 | Box | Active | 12VDC | Square - 60mm L x 60mm H | 25.00mm | 14.7 CFM (0.412m³/min) | 0.150 in H2O (37.3 Pa) | Ball | Tubeaxial | Auto Restart | 25.3dB(A) | 0.72 W | 3500 RPM | 2 Wire Leads | IP68 - Dust Tight, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
(9238S).jpg)
|
CFM-9238S-230-410-22FAN AXIAL 92X37.5MM 24VDC WIRE |
1,280 |
|
Datasheet | CFM-92S | Box | Active | 24VDC | Square - 92mm L x 92mm H | 37.50mm | 57.9 CFM (1.62m³/min) | 0.250 in H2O (62.3 Pa) | Sleeve | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 41.1dB(A) | 4.08 W | 3000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
