DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G4020S12B-RSRFAN AXIAL 40X20MM 12VDC WIRE |
2,174 |
|
Datasheet | G4020 | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 20.00mm | 6.0 CFM (0.168m³/min) | 0.070 in H2O (17.4 Pa) | Ball | Tubeaxial | Thermal Overload Protector (TOP) | 21.0dB(A) | - | 4000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
B5015H05B-BSRFAN BLOWER 51X15.7MM 5VDC WIRE |
3,618 |
|
Datasheet | B5015 | Bulk | Active | 5VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 4.0 CFM (0.112m³/min) | 0.560 in H2O (139.5 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 40.0dB(A) | - | 5500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
|
B5015H12B-BSRFAN BLOWER 51X15.7MM 12VDC WIRE |
4,342 |
|
Datasheet | B5015 | Bulk | Active | 12VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 4.0 CFM (0.112m³/min) | 0.560 in H2O (139.5 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 40.0dB(A) | - | 5500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
|
B5015H24B-BSRFAN BLOWER 51X15.7MM 24VDC WIRE |
1,855 |
|
Datasheet | B5015 | Bulk | Active | 24VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 4.0 CFM (0.112m³/min) | 0.560 in H2O (139.5 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 40.0dB(A) | - | 5500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
|
B5015M05B-BSRFAN BLOWER 51X15.7MM 5VDC WIRE |
3,250 |
|
Datasheet | B5015 | Bulk | Active | 5VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 3.0 CFM (0.084m³/min) | 0.350 in H2O (87.2 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 35.0dB(A) | - | 4500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
|
B5015M12B-BSRFAN BLOWER 51X15.7MM 12VDC WIRE |
1,684 |
|
Datasheet | B5015 | Bulk | Active | 12VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 3.0 CFM (0.084m³/min) | 0.350 in H2O (87.2 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 35.0dB(A) | - | 4500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
|
B5015M24B-BSRFAN BLOWER 51X15.7MM 24VDC WIRE |
1,669 |
|
Datasheet | B5015 | Bulk | Active | 24VDC | Square/Rounded - 51mm L x 51mm H | 15.70mm | 3.0 CFM (0.084m³/min) | 0.350 in H2O (87.2 Pa) | Ball | Blower | Thermal Overload Protector (TOP) | 35.0dB(A) | - | 4500 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.062 lb (28.12 g) |
|
MR6025E24B-RSRFAN AXIAL 60X25.5MM 24VDC WIRE |
2,297 |
|
Datasheet | MR6025 | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 25.50mm | 36.6 CFM (1.03m³/min) | 0.640 in H2O (159.4 Pa) | Ball | Tubeaxial | Auto Restart | 50.0dB(A) | - | 7500 RPM | 2 Wire Leads | - | - | - | - |
|
|
MR6025L24B-RSRFAN AXIAL 60X25.5MM 24VDC WIRE |
1,478 |
|
Datasheet | MR6025 | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 25.50mm | 21.9 CFM (0.613m³/min) | 0.230 in H2O (57.3 Pa) | Ball | Tubeaxial | Auto Restart | 35.0dB(A) | - | 4500 RPM | 2 Wire Leads | - | - | - | - |
|
|
MR6025E12B-RSRFAN AXIAL 60X25.5MM 12VDC WIRE |
3,498 |
|
Datasheet | MR6025 | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 25.50mm | 36.6 CFM (1.03m³/min) | 0.640 in H2O (159.4 Pa) | Ball | Tubeaxial | Auto Restart | 50.0dB(A) | - | 7500 RPM | 2 Wire Leads | - | - | - | - |
