Sensor Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Sensor Type | Sensing Range | Interface | Sensitivity | Voltage - Supply | Embedded | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HEDS-9830EVBAEDR-9830 318LPI EVAL BOARD-CW |
2,061 |
|
Datasheet | HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3.3V, 5V | No | Board(s) | AEDR-9830 |
|
|
HEDS-9830DPEVBAEDR-9830DP 318LPI EVAL BOARD-CW |
2,715 |
|
- |
HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3V ~ 3.6V, 4.5V ~ 5.5V | No | Board(s) | AEDR-9830DP |
|
|
HEDS-9940EVB1EVAL BOARD 2 CW 200 360 500 625C |
2,096 |
|
- |
HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3V ~ 3.6V, 4.5V ~ 5.5V | No | Board(s) | AEDR-9940 |
|
|
HEDS-9940EVBLEVAL BOARD 2 CODE STRIPS 128UM |
1,375 |
|
- |
HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3V ~ 3.6V, 4.5V ~ 5.5V | No | Board(s) | AEDR-9940 |
|
|
HEDS-9940EVBEVAL BOARD 2 CW 256 400 512 720C |
1,706 |
|
- |
HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3V ~ 3.6V, 4.5V ~ 5.5V | No | Board(s) | AEDR-9940 |
|
|
HEDS-9930ELEVBAEDR-9930EL LINEAR EVB-CODESTRIP |
1,347 |
|
- |
- | Bulk | Active | Encoder, Optical | - | - | - | - | - | Board(s) | AEDR-9930 |
|
|
HEDS-9830DPEVBLAEDR-9830DP 318LPI EVAL BOARD-CS |
4,382 |
|
- |
HEDS | Bulk | Active | Encoder, Optical | - | Digital | - | 3V ~ 3.6V, 4.5V ~ 5.5V | No | Board(s) | AEDR-9830DP |
|
|
HEDS-9930EEVBAEDR-9930E ROTARY 397LPI EVAL BO |
4,277 |
|
- |
- | Bulk | Active | Encoder, Optical | - | - | - | - | - | Board(s) | AEDR-9930 |
|
|
HEDS-9930E1EVBAEDR-9930E ROTARY 397LPI EVAL BO |
4,510 |
|
- |
- | Bulk | Active | Encoder, Optical | - | - | - | - | - | Board(s) | AEDR-9930 |
|
|
4101QTR-HD-01RC REF SENSOR 1CHNL |
174 |
|
Datasheet | - | Bulk | Active | Phototransistor | 5mm ~ 30mm | Digital | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTR-HD-01RC |
|
|
4201QTR-HD-01A REF SENSOR 1CHNL |
107 |
|
Datasheet | - | Bulk | Active | Phototransistor | 5mm ~ 30mm | Analog | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTR-HD-01A |
|
|
4441QTRX-MD-01A REF SENSOR 1CHNL |
353 |
|
Datasheet | - | Bulk | Active | Phototransistor | 10mm ~ 30mm | Analog | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRX-MD-01A |
|
4541QTRXL-MD-01RC REF SENSOR 1CHNL |
341 |
|
Datasheet | - | Bulk | Active | Phototransistor | 20mm ~ 80mm | Digital | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRXL-MD-01RC |
|
4341QTRX-MD-01RC REF SENSOR 1CHNL |
340 |
|
Datasheet | - | Bulk | Active | Phototransistor | 10mm ~ 30mm | Digital | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRX-MD-01RC |
|
4641QTRXL-MD-01A REF SENSOR 1CHNL |
150 |
|
Datasheet | - | Bulk | Active | Phototransistor | 20mm ~ 80mm | Analog | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRXL-MD-01A |
|
4501QTRXL-HD-01RC REF SENSOR 1CHNL |
275 |
|
Datasheet | - | Bulk | Active | Phototransistor | 20mm ~ 80mm | Digital | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRXL-HD-01RC |
|
|
4601QTRXL-HD-01A REF SENSOR 1CHNL |
102 |
|
Datasheet | - | Bulk | Active | Phototransistor | 20mm ~ 80mm | Analog | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTRXL-HD-01A |
|
2453ACS711EX CURRENT SENSOR +/-31A |
286 |
|
Datasheet | - | Bulk | Active | Current Sensor | ±31A | Analog | 68mV/A | 3V ~ 5.5V | Yes | Board(s), Accessories | ACS711 |
|
2452ACS711EX CURRENT SENSOR +/-15.5A |
231 |
|
Datasheet | - | Bulk | Active | Current Sensor | ±15.5A | Analog | 136mV/A | 3V ~ 5.5V | Yes | Board(s), Accessories | ACS711 |
|
4243QTR-MD-03A REF ARRAY 3CHNL |
130 |
|
Datasheet | - | Bulk | Active | Phototransistor | 5mm ~ 30mm | Analog | - | 2.9V ~ 5.5V | Yes | Board(s), Accessories | QTR-MD-03A |
