DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Main Purpose | Outputs and Type | Voltage - Output | Current - Output | Voltage - Input | Regulator Topology | Frequency - Switching | Contents | Utilized IC / Part | Power - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAXREFDES115A#EVAL BOARD FOR MAX17599 |
3,630 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 20 W | 5V | 4A | 18V ~ 36V | Flyback | 250kHz | Board(s) | MAX17599 |
|
MAXREFDES125#EVAL BOARD FOR MAX17536 |
3,041 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | 20 W | 5.1V | 4A | 17V ~ 36V | Buck | - | Board(s) | MAX17536 |
|
MAXREFDES112A#EVAL BOARD FOR MAX17596 |
1,061 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 10 W | 12V | 800mA | 17V ~ 36V | Flyback | 500kHz | Board(s) | MAX17596 |
|
MAXREFDES113A#EVAL BOARD FOR MAX17596 |
1,146 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 20 W | 12V | 1.6A | 17V ~ 36V | Flyback | 200kHz | Board(s) | MAX17596 |
|
|
MAXREFDES113B#EVAL BOARD FOR MAX17596 |
3,606 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 20 W | 12V | 1.6A | 17V ~ 36V | Flyback | 200kHz | Board(s) | MAX17596 |
|
MAXREFDES114A#EVAL BOARD FOR MAX17599 |
1,596 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 10 W | 5V | 2A | 17V ~ 36V | Flyback | 350kHz | Board(s) | MAX17599 |
|
MAXREFDES116A#EVAL BOARD FOR MAX17599 |
4,160 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 40 W | 5V | 8A | 17V ~ 36V | Flyback | 350kHz | Board(s) | MAX17599 |
|
|
MAXREFDES116B#EVAL BOARD FOR MAX17599 |
3,014 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 40 W | 5V | 8A | 17V ~ 36V | Flyback | 350kHz | Board(s) | MAX17599 |
|
MAXREFDES121C#EVAL BOARD FOR MAX17599 |
1,591 |
|
Datasheet | - | Box | Active | DC/DC Converter | 1 Isolated Output | 33 W | 3.3V | 10A | 18V ~ 36V | Forward Converter | 250kHz | Board(s) | MAX17599 |
|
MAX5026EVKITEVAL BOARD FOR MAX5026 |
2,541 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 30V | 6mA | 3V ~ 11V | Boost | 500kHz | Board(s) | MAX5026 |
