Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RD8127-16-12M0CMC 12MH 16A 2LN TH |
2,842 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 12 mH @ 1 kHz | 16A (Typ) | 20.05mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8127-25-5M0CMC 5MH 25A 2LN TH |
3,547 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 5 mH @ 400 Hz | 25A (Typ) | 8.45mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8137-16-5M0CMC 5MH 16A 3LN TH |
2,499 |
|
Datasheet | - | Power Line | 3 | - | 5 mH @ 400 Hz | 16A (Typ) | 11.6mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
|
RD8137-25-2M5CMC 2.5MH 25A 3LN TH |
3,014 |
|
Datasheet | - | Power Line | 3 | - | 2.5 mH @ 400 Hz | 25A (Typ) | 6.4mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8127-50-1M0CMC 1MH 50A 2LN TH |
1,704 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 1 mH @ 1 kHz | 50A (Typ) | 2.5mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
|
RD8137-36-1M5CMC 1.5MH 36A 3LN TH |
3,913 |
|
Datasheet | - | Power Line | 3 | - | 1.5 mH @ 1 kHz | 36A (Typ) | 3.65mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8127-64-0M8CMC 800UH 64A 2LN TH |
1,116 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 800 µH @ 400 Hz | 64A (Typ) | 1.6mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8147-25-1M3CMC 1.3MH 25A 4LN TH |
3,494 |
|
Datasheet | Horizontal, 8 PC Pin | Power Line | 4 | - | 1.3 mH @ 400 Hz | 25A (Typ) | 5.05mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8147-36-0M8CMC 800UH 36A 4LN TH |
4,965 |
|
Datasheet | Horizontal, 8 PC Pin | Power Line | 4 | - | 800 µH @ 1 kHz | 36A (Typ) | 3mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
|
RD8147-50-0M3CMC 300UH 50A 4LN TH |
1,006 |
|
Datasheet | Horizontal, 8 PC Pin | Power Line | 4 | - | 300 µH @ 400 Hz | 50A (Typ) | 1.75mOhm (Typ) | 850V | 600V | -25°C ~ 110°C | - | - | - | - | - |
