Ceramic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | Temperature Coefficient | Operating Temperature | Features | Ratings | Applications | Failure Rate | Mounting Type | Package / Case | Size / Dimension | Height - Seated (Max) | Thickness (Max) | Lead Spacing | Lead Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
62O472MPKCACAP CER 4700PF 400VAC RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 4700 pF | ±20% | 400VAC | - | -40°C ~ 125°C | - | X1, Y2 | Safety | - | Through Hole | Radial, Disc | 0.591" Dia (15.00mm) | 0.236" (6.00mm) | - | 0.492" (12.50mm) | Straight |
|
62O681KBDCACAP CER 680PF 400VAC RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 680 pF | ±10% | 400VAC | - | -40°C ~ 125°C | - | X1, Y2 | Safety | - | Through Hole | Radial, Disc | 0.276" Dia (7.00mm) | 0.157" (4.00mm) | - | 0.295" (7.50mm) | Straight |
|
|
62O681MADCACAP CER 680PF 400VAC RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 680 pF | ±20% | 400VAC | - | -40°C ~ 125°C | - | X1, Y2 | Safety | - | Through Hole | Radial, Disc | 0.276" Dia (7.00mm) | 0.157" (4.00mm) | - | 0.197" (5.00mm) | Straight |
|
|
62O681MBDCACAP CER 680PF 400VAC RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 680 pF | ±20% | 400VAC | - | -40°C ~ 125°C | - | X1, Y2 | Safety | - | Through Hole | Radial, Disc | 0.276" Dia (7.00mm) | 0.157" (4.00mm) | - | 0.295" (7.50mm) | Straight |
|
65N103MCJIACAP CER 10000PF 250VAC RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 10000 pF | ±20% | 250VAC | - | -40°C ~ 125°C | - | X2, Y3 | Safety | - | Through Hole | Radial, Disc | 0.512" Dia (13.00mm) | 0.236" (6.00mm) | - | 0.394" (10.00mm) | Straight |
|
|
67S102MCECACAP CER 1000PF 2KV Y5U RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 1000 pF | ±20% | 2000V (2kV) | Y5U (E) | -40°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial, Disc | 0.315" Dia (8.00mm) | 0.157" (4.00mm) | - | 0.394" (10.00mm) | Straight |
|
|
67S103MCLCPCAP CER 10000PF 2KV Y5U RADIAL |
0 |
|
Datasheet | - | Tape & Box (TB) | Obsolete | 10000 pF | ±20% | 2000V (2kV) | Y5U (E) | -40°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial, Disc | - | - | - | 0.394" (10.00mm) | Straight |
|
68S103ZBHCECAP CER 10000PF 2KV Y5V RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 10000 pF | -20%, +80% | 2000V (2kV) | Y5V (F) | -40°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial, Disc | 0.433" Dia (11.00mm) | 0.197" (5.00mm) | - | 0.295" (7.50mm) | Straight |
|
6HQ6R8DAADACAP CER 6.8PF 500V N1500 RADIAL |
0 |
|
- |
- | Bulk | Obsolete | 6.8 pF | ±0.5pF | 500V | N1500 | -55°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial, Disc | 0.157" Dia (4.00mm) | 0.118" (3.00mm) | - | 0.197" (5.00mm) | Straight |
|
|
6LR152KAHCDCAP CER 1500PF 1KV Y5P RADIAL |
0 |
|
Datasheet | - | Bulk | Obsolete | 1500 pF | ±10% | 1000V (1kV) | Y5P (B) | -40°C ~ 125°C | - | - | General Purpose | - | Through Hole | Radial, Disc | 0.433" Dia (11.00mm) | 0.197" (5.00mm) | - | 0.197" (5.00mm) | Straight |
