Cable and Cord Grips
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Type | Outside Cable Diameter (Min) | Outside Cable Diameter (Max) | Thread Size | Thread Length | Conduit Hub Size | Panel Hole Size | Material | Includes | Color | Ingress Protection | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1461180000CABLE GLAND 22-32MM M40 POLYAMID |
2,952 |
|
- |
Cable Gland | 0.866" (22.00mm) | 1.260" (32.00mm) | M40 | 0.709" (18.01mm) | - | - | Polyamide (PA6), Nylon 6 | Seal | Black | IP54/IP66/IP67/IP68 - Dust Protected, Dust Tight, Water Resistant, Waterproof | -40°C ~ 80°C | |
|
|
1491000000CABLE GLAND 17-25MM PG29 |
2,734 |
|
Datasheet | Cable Gland | 0.669" (17.00mm) | 0.984" (25.00mm) | PG29 | 0.472" (12.00mm) | - | - | Polyamide (PA), Nylon | Seal | Black | IP66/IP68 - Dust Tight, Water Resistant, Waterproof | -20°C ~ 80°C | |
|
|
951895CABLE GLAND PG21 |
2,733 |
|
- |
Cable Gland | - | - | PG21 | - | - | - | - | - | Black | - | - | |
|
|
1720380000CABLE GLND 14-18.01MM PG21 BRASS |
1,769 |
|
Datasheet | Cable Gland | 0.551" (14.00mm) | 0.709" (18.01mm) | PG21 | 0.276" (7.00mm) | - | - | Brass, Nickel Plated | Strain Relief | Silver | IP65 - Dust Tight, Water Resistant | -10°C ~ 80°C | |
|
|
951911CABLE GLAND PG21 |
1,851 |
|
- |
Cable Gland | - | - | PG21 | - | - | - | - | - | - | - | - | |
|
|
1737390000CABLE GLAND 24-32MM M40 POLYAMID |
2,420 |
|
Datasheet | Cable Gland | 0.945" (24.00mm) | 1.260" (32.00mm) | M40x1.5 | 0.591" (15.00mm) | - | - | Polyamide (PA), Nylon | Seal | Blue | IP66/IP68 - Dust Tight, Water Resistant, Waterproof | -20°C ~ 80°C | |
|
1706860000CABLE GLAND 6.5-9.5MM PG9 BRASS |
2,457 |
|
Datasheet | Cable Gland | 0.256" (6.50mm) | 0.374" (9.50mm) | PG9 | 0.236" (6.00mm) | - | - | Brass, Nickel Plated | O-Ring, Seal | Silver | IP68 - Dust Tight, Waterproof | -40°C ~ 135°C | |
|
|
1461090000CABLE GLAND 22-32MM M40 POLYAMID |
4,987 |
|
- |
Cable Gland | 0.866" (22.00mm) | 1.260" (32.00mm) | M40 | 0.709" (18.01mm) | - | - | Polyamide (PA6), Nylon 6 | Seal | Multiple | IP54/IP66/IP67/IP68 - Dust Protected, Dust Tight, Water Resistant, Waterproof | -40°C ~ 80°C | |
|
|
0930481212KSG M20 BS O SC 2 G16 |
1,074 |
|
Datasheet | Cable Gland | 0.157" (4.00mm) | 0.331" (8.40mm) | M20 | 0.630" (16.00mm) | - | - | Brass | - | Silver | IP66/IP68 - Dust Tight, Water Resistant, Waterproof | -60°C ~ 180°C | |
|
|
1136720000KSG M20 BS O SC 2 G20S |
3,188 |
|
Datasheet | Cable Gland | 0.283" (7.20mm) | 0.461" (11.70mm) | M20 | 0.630" (16.00mm) | - | - | Brass | - | Silver | IP66/IP68 - Dust Tight, Water Resistant, Waterproof | -60°C ~ 180°C |
