Audio Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1645XFMR 5KCT / 4, 8, 16, 70V CHAS |
2,864 |
|
Datasheet | 1600 | Bulk | Active | - | 5kCT | 4, 8, 16, 70V | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | - | ±1dB | - | 30W | - | - | Chassis Mount | 3.750" L x 2.500" W (95.25mm x 63.50mm) | 3.060" (77.72mm) | Wire Leads |
|
1140-MS-CAUDIO XFMR 150 CHAS MNT |
1,148 |
|
Datasheet | 1140 | Bulk | Active | - | 150 | - | 48Ohm | - | Impedance Matching | 20Hz ~ 20kHz | - | 500Vrms | - | - | - | - | - | Chassis Mount | - | 1.732" (43.99mm) | Wire Leads |
|
|
1750WRAUDIO XFMR 2K CHAS MNT |
4,150 |
|
Datasheet | 1750 | Bulk | Active | - | 2k | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 40Hz ~ 15kHz | -1dB | 2000V | - | - | - | -40°C ~ 105°C | - | Chassis Mount | - | 3.500" (88.90mm) | Wire Leads |
|
|
1650LAAUDIO XFMR CHAS MNT |
4,308 |
|
Datasheet | 1650A | Bulk | Active | - | - | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | - | - | - | - | - | - | - | - | Chassis Mount | - | - | Wire Leads |
|
|
1750WAAUDIO XFMR 2K CHAS MNT |
4,091 |
|
Datasheet | 1750 | Bulk | Active | - | 2k | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | -1dB | 2000V | - | - | 100W | -40°C ~ 105°C | - | Chassis Mount | - | 3.500" (88.90mm) | Wire Leads |
|
|
1750TCAUDIO XFMR CHAS MNT |
2,531 |
|
Datasheet | 175 | Bulk | Active | - | - | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | - | - | - | - | - | 120W | - | - | Chassis Mount | - | - | Wire Leads |
|
|
PWDM13041AUDIO XFMR |
3,380 |
|
Datasheet | * | Case | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1650MAUDIO XFMR CHAS MNT |
4,309 |
|
Datasheet | 1650P | Bulk | Active | - | - | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | - | - | - | - | - | - | - | - | Chassis Mount | - | - | Wire Leads |
|
|
1760CGPWAUDIO XFMR CHAS MNT |
2,406 |
|
Datasheet | 1750 | Bulk | Active | - | - | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | - | - | - | - | - | 100W | - | - | Chassis Mount | - | - | Wire Leads |
|
|
1650KAPAUDIO XFMR CHAS MNT |
4,905 |
|
Datasheet | 1650P | Bulk | Active | - | - | - | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | - | - | - | - | - | - | - | - | Chassis Mount | - | - | Wire Leads |
