Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL205675223E3CAP ALUM 22000UF 20% 16V SNAP TH |
0 |
|
Datasheet | 056 PSM-SI | Tape & Box (TB) | Active | 22000 µF | ±20% | 16 V | 33mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 4.51 A @ 100 Hz | - | 28 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
MAL225782182E3CAP ALUM 1800UF 20% 200V SNAP TH |
0 |
|
- |
257 PRM-SI | Box | Active | 1800 µF | ±20% | 200 V | 100mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.03 A @ 100 Hz | 5.642 A @ 10 kHz | 80 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
MAL225732182E3CAP ALUM 1800UF 20% 200V SNAP TH |
0 |
|
- |
257 PRM-SI | Box | Active | 1800 µF | ±20% | 200 V | 100mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.03 A @ 100 Hz | 5.642 A @ 10 kHz | 80 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
MAL212016472E3CAP ALUM 4700UF 20% 25V AXIAL TH |
0 |
|
Datasheet | 120 ATC | Bulk | Active | 4700 µF | ±20% | 25 V | 27mOhm | 8000 Hrs @ 125°C | -40°C ~ 125°C | - | AEC-Q200 | Automotive | - | 4.47 A @ 10 kHz | 29 mOhms | - | 0.827" Dia x 1.496" L (21.00mm x 38.00mm) | - | - | Through Hole | |
|
MAL215617103E3CAP ALUM 10000UF 20% 40V SNAP TH |
0 |
|
Datasheet | 156 PUM-SI | Bulk | Active | 10000 µF | ±20% | 40 V | 60mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.02 A @ 100 Hz | - | 38 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL215657103E3CAP ALUM 10000UF 20% 40V SNAP TH |
0 |
|
Datasheet | 156 PUM-SI | Bulk | Active | 10000 µF | ±20% | 40 V | 60mOhm @ 100Hz | 5000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.02 A @ 100 Hz | - | 38 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL225932152E3CAP ALUM 1500UF 20% 200V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 1500 µF | ±20% | 200 V | 100mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.58 A @ 100 Hz | 5.37 A @ 10 kHz | 70 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
|
MAL225972152E3CAP ALUM 1500UF 20% 200V SNAP TH |
0 |
|
- |
259 PHM-SI | Box | Active | 1500 µF | ±20% | 200 V | 100mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.58 A @ 100 Hz | 5.37 A @ 10 kHz | 70 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
MAL209332152E3CAP ALUM 1500UF 20% 200V SNAP TH |
0 |
|
Datasheet | 093 PMG-SI | Tape & Box (TB) | Active | 1500 µF | ±20% | 200 V | 120mOhm @ 120Hz | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3 A @ 120 Hz | - | 90 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
MAL209333821E3CAP ALUM 820UF 20% 250V SNAP TH |
0 |
|
Datasheet | 093 PMG-SI | Tape & Box (TB) | Active | 820 µF | ±20% | 250 V | 190mOhm @ 120Hz | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 2.23 A @ 120 Hz | - | 130 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole |
