Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
35RX30470MT810X20CAP ALUM 470UF 20% 35V RADIAL TH |
476 |
|
Datasheet | RX30 | Cut Tape (CT) | Active | 470 µF | ±20% | 35 V | - | 2000 Hrs @ 130°C | -40°C ~ 130°C | Polar | AEC-Q200 | Automotive | 720 mA @ 120 Hz | 960 mA @ 100 kHz | 73 mOhms | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.866" (22.00mm) | - | Through Hole | |
|
450VXH150MEFCSN22X35CAP ALUM 150UF 20% 450V SNAP TH |
28 |
|
Datasheet | VXH | Bulk | Active | 150 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.13 A @ 120 Hz | 1.582 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
100YXJ4R7M5X11CAP ALUM 4.7UF 20% 100V RADIAL |
727 |
|
Datasheet | YXJ | Bulk | Active | 4.7 µF | ±20% | 100 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 27.3 mA @ 120 Hz | 65 mA @ 100 kHz | 2.5 Ohms | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
10YXJ100MTA5X11CAP ALUM 100UF 20% 10V RADIAL TH |
842 |
|
Datasheet | YXJ | Tape & Reel (TR) | Active | 100 µF | ±20% | 10 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 105 mA @ 120 Hz | 150 mA @ 100 kHz | 900 mOhms | 0.197" (5.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
50YXJ3.3M5X11CAP ALUM 3.3UF 20% 50V RADIAL TH |
903 |
|
Datasheet | YXJ | Bulk | Active | 3.3 µF | ±20% | 50 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 22.26 mA @ 120 Hz | 53 mA @ 100 kHz | 2.2 Ohms | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
25YXS100MEFC5X11CAP ALUM 100UF 20% 25V RADIAL TH |
934 |
|
Datasheet | YXS | Bulk | Active | 100 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 105 mA @ 120 Hz | 210 mA @ 100 kHz | 580 mOhms | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
50YXJ2R2MTA5X11CAP ALUM 2.2UF 20% 50V RADIAL TH |
269 |
|
Datasheet | YXJ | Cut Tape (CT) | Active | 2.2 µF | ±20% | 50 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 18.06 mA @ 120 Hz | 43 mA @ 100 kHz | 2.5 Ohms | 0.197" (5.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
50PK4.7MEFC5X11CAP ALUM 4.7UF 20% 50V RADIAL TH |
188 |
|
Datasheet | PK | Bulk | Active | 4.7 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 41 mA @ 120 Hz | 61.5 mA @ 10 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
10YXJ100M5X11CAP ALUM 100UF 20% 10V RADIAL TH |
894 |
|
Datasheet | YXJ | Bulk | Active | 100 µF | ±20% | 10 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 105 mA @ 120 Hz | 150 mA @ 100 kHz | 900 mOhms | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
25TWL10MEFC5X11CAP ALUM 10UF 20% 25V RADIAL TH |
828 |
|
Datasheet | TWL | Bulk | Active | 10 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 75 mA @ 10 kHz | - | 0.079" (2.00mm) | 0.197" Dia (5.00mm) | 0.492" (12.50mm) | - | Through Hole |
